| TGB's profilation of this bike |
| As the meaning of the word, Delivery scooter has been specially designed for commercial use. It has purpose built frame for low gravity center and adapted rear-twin shock absorbers. Instead of one main stand, we equipped L/R latching side stands that have built-in engine cut off. |
|
General moped information |
|
Motorcycle name
|
TGB Express 50 |
|
Year
|
2011 |
|
Category
|
Scooter |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Displacement
|
49.0 ccm (2.99 cubic inches) |
|
Engine type
|
Single cylinder, two-stroke |
|
Power
|
4.9 HP (3.6 kW)) |
|
Compression
|
9.2:1 |
|
Bore x stroke
|
41.0 x 37.4 mm (1.6 x 1.5 inches) |
|
Fuel system
|
Carburettor |
|
Ignition
|
CDI |
|
Lubrication system
|
Separate oil pump |
|
Cooling system
|
Air |
|
Gearbox
|
Automatic |
|
Transmission type
|
Belt (final drive) |
|
Emission details
|
EC and DOT/EPA approval |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Telescopic fork |
|
Rear suspension
|
Twin rear shock absorbers |
|
Front tire
|
3.00-14 |
|
Rear tire
|
120/70-12 |
|
Front brakes
|
Single disc |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Wheels
|
Alloy wheels |
|
Physical measures and capacities |
|
Dry weight
|
105.0 kg (231.5 pounds) |
|
Power/weight ratio
|
0.0467 HP/kg |
|
Seat height
|
760 mm (29.9 inches) If adjustable, lowest setting. |
|
Overall height
|
1150 mm (45.3 inches) |
|
Overall length
|
1910 mm (75.2 inches) |
|
Overall width
|
660 mm (26.0 inches) |
|
Fuel capacity
|
6.80 litres (1.80 US gallons) |
|
Other specifications |
|
Color options
|
Blue, red, yellow |
|
Starter
|
Electric & kick |
|
Electrical
|
12 Volt |
|
Carrying capacity
|
Top case of 150L |
|
Comments
|
Made in Taiwan |
