| Terra Modena's profilation of this bike |
| Technology and style are born from an unique Italian motor industry tradition: the shape of the 198 forms a single clean line , from its front nose to its slim tail-end |
|
General information |
|
Motorcycle name
|
Terra Modena 198 |
|
Year
|
2012 |
|
Category
|
Sport |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Displacement
|
449.6 ccm (27.43 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Engine details
|
Titanium valves. Sand casted aluminium engine block. |
|
Max RPM
|
9000 |
|
Bore x stroke
|
98.0 x 59.6 mm (3.9 x 2.3 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Injection. Indirect injection. Dell’Orto Ø 50mm throttle body. |
|
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
|
Ignition
|
Magneti Marelli |
|
Lubrication system
|
Separate lubrication system with one pressure pump and two scavenge pumps |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Surflex anti-hop clutch, with ergal cover; wet, multiple hydraulically operated plates. |
|
Driveline
|
Primary distribution fitted with sprocket gears |
|
Emission details
|
Euro 3 |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Aluminium alloy Alsi 9 double bean main frame with a twin under mount. |
|
Rake (fork angle)
|
26.0° |
|
Front suspension
|
Ohlins upside-down front suspension fork with 46 mm diameter rods and adjustable compression, rebound and pre-stressing |
|
Rear suspension
|
Rear swinging fork and Ohlins DPS 46 mm single shock absorber fitted with inert gas cartridge and separator piston. |
|
Front tire
|
120/70-ZR17 |
|
Rear tire
|
160/60-ZR17 |
|
Front brakes
|
Single disc |
|
Diameter
|
320 mm (12.6 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
220 mm (8.7 inches) |
|
Wheels
|
Marchesini, in cast aluminium |
|
Physical measures and capacities |
|
Dry weight
|
120.0 kg (264.6 pounds) |
|
Seat height
|
890 mm (35.0 inches) If adjustable, lowest setting. |
|
Overall height
|
1185 mm (46.7 inches) |
|
Overall length
|
2150 mm (84.6 inches) |
|
Overall width
|
830 mm (32.7 inches) |
|
Wheelbase
|
1048 mm (41.3 inches) |
|
Fuel capacity
|
8.50 litres (2.25 US gallons) |
|
Reserve fuel capacity
|
1.00 litres (0.26 US gallons) |
|
Other specifications |
|
Starter
|
Electric & kick |
|
Electrical
|
12 V - 9Ah battery |
|
Comments
|
Italian made bike. |
