| Sym's profilation of this bike |
| QuadRaider 600 offers massive power with comfortable and stylish ATV design. The liquid-cooling engine provides durability for long distance trips. |
|
General information |
|
Model name
|
Sym Quad Raider 600 |
|
Year
|
2011 |
|
Category
|
ATV |
|
Rating
|
3.7 Check out the detailed rating of reliability, maintenance costs, value for money, etc. Compare with any other motorcycle. |
|
Engine and transmission |
|
Displacement
|
565.0 ccm (34.48 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Engine details
|
Electroplated ceramic cylinder |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Carburettor |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Cooling system
|
Liquid |
|
Gearbox
|
Automatic |
|
Transmission type
|
Shaft drive (cardan) (final drive) |
|
Driveline
|
Automatic CVT with reverse. |
|
Emission details
|
Euro 2 for EU and EPA / DOT / CARB for the US |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Independent, Double A-arm/unit swing arm |
|
Rear suspension
|
Unit Swing Arm |
|
Front tire
|
25/8-12 |
|
Rear tire
|
25/10-12 |
|
Front brakes
|
Double disc. Hydraulic |
|
Diameter
|
220 mm (8.7 inches) |
|
Rear brakes
|
Single disc. With parking |
|
Diameter
|
190 mm (7.5 inches) |
|
Physical measures and capacities |
|
Dry weight
|
345.0 kg (760.6 pounds) |
|
Overall height
|
1220 mm (48.0 inches) |
|
Overall length
|
2110 mm (83.1 inches) |
|
Overall width
|
1150 mm (45.3 inches) |
|
Wheelbase
|
1300 mm (51.2 inches) |
|
Fuel capacity
|
17.00 litres (4.49 US gallons) |
|
Other specifications |
|
Color options
|
Green, red, blue, beige |
|
Starter
|
Electric & kick |
|
Light
|
12V 35W / 35W X 2 headlights |
|
Carrying capacity
|
Front and rear rack |
|
Comments
|
ATV made in Taiwan. Model versions called SYM QuadRaider 600 LE and SYM QuadRaider 600 US. Not all colors available for all versions. |
