General information |
|
Model
|
Suzuki Marauder 800 |
|
Year of manufacture
|
2004 |
|
Type
|
Custom / cruiser |
| Price as new | US$ 5999. MSRP depends on country, taxes, accessories, etc. |
|
Rating
|
3.8 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
805.0 ccm (49.12 cubic inches) |
|
Type of engine
|
V2, four-stroke |
|
Torque
|
65.0 Nm (6.6 kgf-m or 47.9 ft.lbs) |
|
Top speed
|
164.0 km/h (101.9 mph) |
|
Compression
|
10.0:1 |
|
Bore x stroke
|
83.0 x 74.4 mm (3.3 x 2.9 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Carburettor |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Ignition
|
Digital transistorized |
|
Cooling system
|
Liquid |
|
Gearbox
|
5-speed |
|
Transmission type
|
Chain (final drive) |
|
Fuel consumption
|
6.20 litres/100 km (16.1 km/l or 37.94 mpg) |
|
Greenhouse gases
|
143.8 CO2 g/km. (CO2 - Carbon dioxide emission) |
|
Chassis, suspension, brakes and wheels |
|
Rake (fork angle)
|
35.0° |
|
Front suspension
|
Inverted telescopic, coil spring, oil damped |
|
Front wheel travel
|
140 mm (5.5 inches) |
|
Rear suspension
|
Swingarm, oil damped, 5-way adjustable spring preload |
|
Rear wheel travel
|
102 mm (4.0 inches) |
|
Front tire
|
130/90-H16 |
|
Rear tire
|
150/90-M15 |
|
Front brakes
|
Single disc. Two-piston calipers. |
|
Diameter
|
310 mm (12.2 inches) |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Diameter
|
180 mm (7.1 inches) |
|
Physical measures and capacities |
|
Dry weight
|
207.0 kg (456.4 pounds) |
|
Seat height
|
700 mm (27.6 inches) If adjustable, lowest setting. |
|
Overall height
|
1110 mm (43.7 inches) |
|
Overall length
|
2365 mm (93.1 inches) |
|
Overall width
|
750 mm (29.5 inches) |
|
Ground clearance
|
135 mm (5.3 inches) |
|
Wheelbase
|
1645 mm (64.8 inches) |
|
Fuel capacity
|
13.00 litres (3.43 US gallons) |
|
Oil capacity
|
2.10 litres (2.22 US quarts) |
|
Other specifications |
|
Color options
|
Black, Blue |
|
Starter
|
Electric |
| Update specs | Report missing specs or required updates. |
|
Maintenance and service specs * |
|
Engine oil
|
SAE 10W-40 |
|
Oil filter
|
EMGO 10-55670, K&N KN-138 |
|
Brake fluid
|
DOT 4 |
|
Coolant
|
1.00 litres (0.26 US gallons) |
|
Battery
|
YTX12-BS |
|
Spark plugs
|
NGK DPR8EA-9, NGK DPR8EIX-9 |
|
Idle speed
|
1200 +/- 100 RPM |
|
Chain size
|
530 |
|
Chain links
|
116 |
|
Sprockets
|
15/48 (front/rear) |
|
Tire pressure front
|
29 PSI (2 Bar or 200 kPa) |
|
Tire pressure rear
|
33 PSI (2.3 Bar or 225 kPa) |
|
Fork tube size
|
41 mm (1.6 inches) |
| *) Always verify maintenance and service data with the bike owner's manual. |
|
