General information |
Motorcycle name
|
Suzuki GSX 750 F |
Model year
|
2006 |
Category
|
Sport touring |
Rating
|
3.7 See the detailed rating of touring capabilities, reliability, accident risk, etc. Compare with any other motorbike. |
Engine and transmission |
Displacement
|
750.0 ccm (45.77 cubic inches) |
Engine type
|
In-line four, four-stroke |
Power output
|
91.3 HP (66.7 kW)) @ 10500 RPM |
Torque
|
67.0 Nm (6.8 kgf-m or 49.4 ft.lbs) @ 9500 RPM |
Compression
|
10.7:1 |
Bore x stroke
|
70.0 x 48.7 mm (2.8 x 1.9 inches) |
Valves per cylinder
|
4 |
Fuel system
|
Carburettor. Mikuni BSR36 x 4 |
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
Ignition
|
Electronic |
Lubrication system
|
Wet sump |
Cooling system
|
Air |
Gearbox
|
6-speed |
Transmission type
|
Chain (final drive) |
Clutch
|
Wet multi plate |
Chassis, suspension, brakes and wheels |
Rake (fork angle)
|
25.3° |
Front suspension
|
Telescopic, 4-way adjustable rebound damping |
Rear suspension
|
Link type, preload and rebound damping adjustable |
Front brakes
|
Double disc |
Diameter
|
290 mm (11.4 inches) |
Rear brakes
|
Single disc |
Diameter
|
240 mm (9.4 inches) |
Physical measures and capacities |
Dry weight
|
187.0 kg (412.3 pounds) |
Power/weight ratio
|
0.4883 HP/kg |
Seat height
|
790 mm (31.1 inches) If adjustable, lowest setting. |
Alternate seat height
|
805 mm (31.7 inches) If adjustable, highest setting. |
Overall height
|
1190 mm (46.9 inches) |
Overall length
|
2140 mm (84.3 inches) |
Overall width
|
760 mm (29.9 inches) |
Ground clearance
|
120 mm (4.7 inches) |
Wheelbase
|
1465 mm (57.7 inches) |
Fuel capacity
|
20.00 litres (5.28 US gallons) |
Other specifications |
Starter
|
Electric |
