General information |
Motorcycle name
|
Suzuki DR-Z400E |
Model year
|
2010 |
Category
|
Enduro / offroad |
Rating
|
3.2 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
Engine and transmission |
Displacement
|
399.0 ccm (24.35 cubic inches) |
Engine type
|
Single cylinder, four-stroke |
Compression
|
12.2:1 |
Bore x stroke
|
90.0 x 62.6 mm (3.5 x 2.5 inches) |
Fuel system
|
Carburettor. Mikuni BSR36 |
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
Ignition
|
Digital/DC-CDI |
Lubrication system
|
Wet sump |
Cooling system
|
Oil & air |
Gearbox
|
5-speed |
Transmission type
|
Chain (final drive) |
Chassis, suspension, brakes and wheels |
Front suspension
|
Telescopic, cartridge-type, oil-damped, adjustable preload, 14-way compression damping and 18-way rebound damping |
Rear suspension
|
Link-type, fully-adjustable spring preload, adjustable high/low compression dampimg and adjustable rebound damping |
Front tire
|
80/0-21 |
Rear tire
|
110/0-18 |
Front brakes
|
Single disc |
Rear brakes
|
Single disc |
Physical measures and capacities |
Dry weight
|
119.0 kg (262.4 pounds) |
Weight incl. oil, gas, etc
|
123.5 kg (272.3 pounds) |
Seat height
|
945 mm (37.2 inches) If adjustable, lowest setting. |
Overall length
|
2235 mm (88.0 inches) |
Overall width
|
825 mm (32.5 inches) |
Ground clearance
|
325 mm (12.8 inches) |
Wheelbase
|
1475 mm (58.1 inches) |
Fuel capacity
|
10.00 litres (2.64 US gallons) |
Other specifications |
Color options
|
Yellow |
Starter
|
Electric |
