General information |
Model name
|
Suzuki Bandit 650 SA |
Year of manufacture
|
2006 |
Type
|
Naked bike |
Rating
|
3.5 See the detailed rating of engine performance, design and look, accident risk, etc. Compare with any other motorcycle. |
Engine and transmission |
Engine size
|
656.0 ccm (40.03 cubic inches) |
Type of engine
|
V4, four-stroke |
Output
|
77.5 HP (56.6 kW)) @ 10100 RPM |
Torque
|
59.2 Nm (6.0 kgf-m or 43.7 ft.lbs) @ 4000 RPM |
Compression
|
10.5:1 |
Bore x stroke
|
65.5 x 48.7 mm (2.6 x 1.9 inches) |
Fuel system
|
Carburettor. Keihin CVR32 |
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
Ignition
|
Digital |
Lubrication system
|
Wet sump |
Cooling system
|
Air |
Gearbox
|
6-speed |
Chassis, suspension, brakes and wheels |
Rake (fork angle)
|
26.0° |
Front suspension
|
41 mm telescopic, coil spring, spring pre-load fully adjustable |
Rear suspension
|
Link type, oil damped, coil spring, spring pre-load 7-way adjustable, rebound damping 4-way adjustable |
Front tire
|
120/70-ZR17 |
Rear tire
|
180/55-ZR17 |
Front brakes
|
Double disc |
Diameter
|
290 mm (11.4 inches) |
Rear brakes
|
Single disc |
Diameter
|
240 mm (9.4 inches) |
Physical measures and capacities |
Dry weight
|
204.0 kg (449.7 pounds) |
Power/weight ratio
|
0.3799 HP/kg |
Seat height
|
770 mm (30.3 inches) If adjustable, lowest setting. |
Overall height
|
1235 mm (48.6 inches) |
Overall length
|
2110 mm (83.1 inches) |
Overall width
|
770 mm (30.3 inches) |
Ground clearance
|
135 mm (5.3 inches) |
Wheelbase
|
1440 mm (56.7 inches) |
Fuel capacity
|
20.00 litres (5.28 US gallons) |
Other specifications |
Starter
|
Electric |
