General information |
|
Model name
|
Shineray XY125GY-6 |
|
Model year
|
2011 |
|
Category
|
Enduro / offroad |
|
Rating
|
2.7 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
124.0 ccm (7.57 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Power output
|
9.9 HP (7.2 kW)) @ 9000 RPM |
|
Torque
|
8.5 Nm (0.9 kgf-m or 6.3 ft.lbs) @ 8000 RPM |
|
Compression
|
9.2:1 |
|
Bore x stroke
|
56.5 x 49.5 mm (2.2 x 1.9 inches) |
|
Fuel system
|
Carburettor |
|
Ignition
|
CDI |
|
Lubrication system
|
Pressure ,splash |
|
Cooling system
|
Air |
|
Gearbox
|
5-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Multiplate wet clutch |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Hydraulic pressure, spring |
|
Rear suspension
|
Hydraulic pressure, spring |
|
Front tire
|
90/90-19 |
|
Rear tire
|
110/90-17 |
|
Front brakes
|
Single disc |
|
Rear brakes
|
Single disc |
|
Seat
|
2-person seat |
|
Physical measures and capacities |
|
Dry weight
|
112.0 kg (246.9 pounds) |
|
Power/weight ratio
|
0.0886 HP/kg |
|
Seat height
|
890 mm (35.0 inches) If adjustable, lowest setting. |
|
Overall height
|
1175 mm (46.3 inches) |
|
Overall length
|
1970 mm (77.6 inches) |
|
Overall width
|
760 mm (29.9 inches) |
|
Ground clearance
|
300 mm (11.8 inches) |
|
Wheelbase
|
1330 mm (52.4 inches) |
|
Fuel capacity
|
5.60 litres (1.48 US gallons) |
|
Other specifications |
|
Color options
|
Black, white |
|
Starter
|
Electric & kick |
|
Electrical
|
12V 4Ah battery |
|
Comments
|
Chinese brand. |
