| Sherco's profilation of this bike |
| The high performance components incorporated in the new SHERCO R include some of the secrets that have until now been used only on the team bikes ridden in World Competition by Cabestany and Oliveras. |
|
General information |
|
Model name
|
Sherco ST Racing 3.2 F |
|
Year of manufacture
|
2009 |
|
Type
|
Trial |
|
Rating
|
3.9 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
317.0 ccm (19.34 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Bore x stroke
|
82.0 x 60.0 mm (3.2 x 2.4 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Carburettor. Keihin 28 |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Lubrication system
|
Wet sump pressure lubrication |
|
Gearbox
|
5-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Wet, multidisc. Racing clutch cylinder. |
|
Exhaust system
|
Carbon fiber exhaust guard. Titanium exhaust header pipe |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Triangulated cross section Chrome-moly. Painted flat black |
|
Front suspension
|
Ceriani 38 mm. dia hydraulic telescope fork, 185 mm travel fully adjustable for preload and dampening. anti friction coating on the fork tubes, Kevlar Fork protectors. Carbon fiber front fork bracket. |
|
Rear suspension
|
Progressive link system with single Olle adjustable shock absorber, 175 mm travel |
|
Rear wheel travel
|
175 mm (6.9 inches) |
|
Front brakes
|
Single disc |
|
Diameter
|
185 mm (7.3 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
145 mm (5.7 inches) |
|
Physical measures and capacities |
|
Dry weight
|
72.0 kg (158.7 pounds) |
|
Seat height
|
625 mm (24.6 inches) If adjustable, lowest setting. |
|
Ground clearance
|
305 mm (12.0 inches) |
|
Wheelbase
|
1322 mm (52.0 inches) |
|
Fuel capacity
|
2.90 litres (0.77 US gallons) |
|
Other specifications |
|
Color options
|
Black/gold |
|
Comments
|
Racing model. |
