| Rokon's profilation of this bike |
| Full time, Front and Rear wheel drive. Amazingly, like all Rokons, the Rokon Ranger leaves a track lighter than a man´s footprint. While it may be kind to the environment, Ranger still has all the ROKON go-anywhere character and reliability. |
|
General information |
|
Motorcycle name
|
Rokon Ranger |
|
Year of manufacture
|
2013 |
|
Type
|
Enduro / offroad |
| Price as new | US$ 6375. MSRP depends on country, taxes, accessories, etc. |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Engine size
|
160.0 ccm (9.76 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Engine details
|
Honda fan-cooled engine |
|
Output
|
5.0 HP (3.6 kW)) @ 3600 RPM |
|
Torque
|
10.9 Nm (1.1 kgf-m or 8.0 ft.lbs) @ 2500 RPM |
|
Fuel system
|
Carburettor. Horizontal type, butterfly valve |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Ignition
|
Transistorized magneto |
|
Cooling system
|
Oil & air |
|
Gearbox
|
3-speed |
|
Transmission type
|
Chain (final drive) |
|
Driveline
|
Full time, front and rear wheel drive. Automatic torque converter into a three-gear range selector. |
|
Exhaust system
|
Muffler and US Forestry approved spark arrestor |
|
Chassis, suspension, brakes and wheels |
|
Front tire
|
5.90-15 |
|
Rear tire
|
5.90-15 |
|
Front brakes
|
Single disc |
|
Rear brakes
|
Single disc |
|
Wheels
|
Steel, spoked |
|
Physical measures and capacities |
|
Dry weight
|
98.8 kg (217.8 pounds) |
|
Power/weight ratio
|
0.0506 HP/kg |
|
Overall length
|
2007 mm (79.0 inches) |
|
Overall width
|
762 mm (30.0 inches) |
|
Ground clearance
|
381 mm (15.0 inches) |
|
Wheelbase
|
1295 mm (51.0 inches) |
|
Fuel capacity
|
10.18 litres (2.69 US gallons) |
|
Other specifications |
|
Color options
|
Red, green, black, camouflage |
|
Starter
|
Kick |
|
Electrical
|
88 watt charging system |
|
Factory warranty
|
1 year limited |
|
Comments
|
The electric starter is optional. |
