| Qlink's profilation of this bike |
| Easy electric starting with backup kick starter provides reliability for the ultimate riding experience.
|
|
General moped information |
|
Model name
|
Qlink Axon 50 |
|
Year of manufacture
|
2008 |
|
Type
|
Scooter |
| Price as new | US$ 1050. MSRP depends on country, taxes, accessories, etc. |
|
Rating
|
3.2 View the detailed rating of value for money, design and look, reliability, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
49.0 ccm (2.99 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Output
|
3.5 HP (2.6 kW)) |
|
Torque
|
2.8 Nm (0.3 kgf-m or 2.1 ft.lbs) @ 6000 RPM |
|
Compression
|
10.5:1 |
|
Bore x stroke
|
39.0 x 41.5 mm (1.5 x 1.6 inches) |
|
Fuel system
|
Carburettor. Mikuni |
|
Ignition
|
CDI |
|
Cooling system
|
Air |
|
Gearbox
|
Automatic |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Straight Tube |
|
Rear suspension
|
Single-Arm |
|
Front tire
|
90/90-10 |
|
Rear tire
|
90/90-10 |
|
Front brakes
|
Single disc |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Physical measures and capacities |
|
Dry weight
|
79.8 kg (176.0 pounds) |
|
Power/weight ratio
|
0.0438 HP/kg |
|
Seat height
|
739 mm (29.1 inches) If adjustable, lowest setting. |
|
Ground clearance
|
104 mm (4.1 inches) |
|
Wheelbase
|
1181 mm (46.5 inches) |
|
Fuel capacity
|
6.32 litres (1.67 US gallons) |
|
Other specifications |
|
Starter
|
Electric & kick |
| Update specs | Report missing specs or required updates. |
|
Further information |
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Parts finder |
Check out our overview of motorcycle webshops at Bikez.info. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 08 Qlink Axon 50 discussion group or the general Qlink discussion group. |
| Related bikes | List related bikes for comparison of specs. |
|
|
|
Rating sample for this Qlink moped
|
Racing track capabilities for the 2008 Qlink Axon 50:
 (43.3 out of 100)
Click here for complete rating. You can also compare bikes.
|
|
