| Pitster Pro's profilation of this bike |
| Who said that an off-road bike has to look like your grandpa´s first ride? The XTR 150 is far from your average trail machine. With Motocross inspired looks, inverted forks, and deep four stroke power no one will guess its only 150c. |
|
General information |
|
Model name
|
Pitster Pro XTR 150 SC |
|
Year of manufacture
|
2012 |
|
Type
|
Enduro / offroad |
| Price as new | US$ 2199. MSRP depends on country, taxes, accessories, etc. |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. |
|
Engine and transmission |
|
Engine size
|
144.6 ccm (8.83 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Compression
|
9.2:1 |
|
Bore x stroke
|
61.0 x 61.0 mm (2.4 x 2.4 inches) |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Ignition
|
Stator/ CDI with lighting coil |
|
Cooling system
|
Air |
|
Gearbox
|
5-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Five plate wet clutch |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
High Tensile Steel |
|
Front suspension
|
Telescopic Fork w/ adj. Compression and Rebound on Each Leg |
|
Rear suspension
|
Piggy Back Reservoir w/ adj. Compression and Rebound |
|
Front tire
|
70/100-17 |
|
Rear tire
|
90/100-14 |
|
Front brakes
|
Single disc |
|
Diameter
|
280 mm (11.0 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
220 mm (8.7 inches) |
|
Wheels
|
Standard |
|
Physical measures and capacities |
|
Dry weight
|
94.4 kg (208.0 pounds) |
|
Seat height
|
889 mm (35.0 inches) If adjustable, lowest setting. |
|
Ground clearance
|
320 mm (12.6 inches) |
|
Wheelbase
|
1295 mm (51.0 inches) |
|
Fuel capacity
|
7.99 litres (2.11 US gallons) |
|
Other specifications |
|
Color options
|
White/black/red |
|
Starter
|
Electric & kick |
