| Piaggio's profilation of this bike |
| The Piaggio Liberty S 50cc is available in Carbon Black with tattoo-style graphics and uses the proven 50cc air-cooled HiPer2 engine to provide quick acceleration and good economy. |
|
General moped information |
|
Model name
|
Piaggio Liberty S 50 |
|
Year
|
2007 |
|
Category
|
Scooter |
|
Rating
|
3.2 View the detailed rating of value for money, design and look, reliability, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
49.0 ccm (2.99 cubic inches) |
|
Engine type
|
Single cylinder, two-stroke |
|
Compression
|
9.9:1 |
|
Bore x stroke
|
40.0 x 39.3 mm (1.6 x 1.5 inches) |
|
Valves per cylinder
|
2 |
|
Fuel system
|
Carburettor |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Cooling system
|
Air |
|
Transmission type
|
Belt (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Front tire
|
90/80-16 |
|
Rear tire
|
110/80-14 |
|
Front brakes
|
Expanding brake (drum brake) |
|
Diameter
|
136 mm (5.4 inches) |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Diameter
|
140 mm (5.5 inches) |
|
Physical measures and capacities |
|
Dry weight
|
83.0 kg (183.0 pounds) |
|
Seat height
|
795 mm (31.3 inches) If adjustable, lowest setting. |
|
Overall length
|
1960 mm (77.2 inches) |
|
Overall width
|
735 mm (28.9 inches) |
|
Wheelbase
|
1330 mm (52.4 inches) |
|
Fuel capacity
|
5.00 litres (1.32 US gallons) |
|
Reserve fuel capacity
|
1.00 litres (0.26 US gallons) |
|
Other specifications |
|
Starter
|
Electric & kick |
