| Piaggio's profilation of this bike |
| Liberty 50 is equipped with the brilliant Piaggio Hi-PER2 50 engine. Level of emissions in compliance with Euro 2 regulation. |
|
General moped information |
|
Motorcycle name
|
Piaggio Liberty Catalyzed |
|
Model year
|
2007 |
|
Category
|
Scooter |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Displacement
|
49.4 ccm (3.01 cubic inches) |
|
Engine type
|
Single cylinder, two-stroke |
|
Power output
|
10.0 HP (7.3 kW)) @ 8000 RPM |
|
Torque
|
10.2 Nm (1.0 kgf-m or 7.5 ft.lbs) @ 6500 RPM |
|
Compression
|
10.3:1 |
|
Bore x stroke
|
40.0 x 39.3 mm (1.6 x 1.5 inches) |
|
Fuel system
|
Carburettor |
|
Ignition
|
Inductive |
|
Lubrication system
|
Wet sump |
|
Cooling system
|
Air |
|
Gearbox
|
Automatic |
|
Transmission type
|
Belt (final drive) |
|
Clutch
|
Dry automatic centrifugal type |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Telescopic fork |
|
Front wheel travel
|
76 mm (3.0 inches) |
|
Rear suspension
|
Hydraulic monoshock |
|
Rear wheel travel
|
83 mm (3.3 inches) |
|
Front tire
|
90/80-16 |
|
Rear tire
|
110/80-14 |
|
Front brakes
|
Single disc |
|
Diameter
|
220 mm (8.7 inches) |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Diameter
|
140 mm (5.5 inches) |
|
Physical measures and capacities |
|
Dry weight
|
87.0 kg (191.8 pounds) |
|
Power/weight ratio
|
0.1149 HP/kg |
|
Seat height
|
775 mm (30.5 inches) If adjustable, lowest setting. |
|
Overall length
|
1900 mm (74.8 inches) |
|
Wheelbase
|
1330 mm (52.4 inches) |
|
Fuel capacity
|
6.00 litres (1.59 US gallons) |
|
Other specifications |
|
Starter
|
Electric & kick |
