General moped information |
|
Motorcycle name
|
Piaggio Free 50 |
|
Model year
|
1992 |
|
Category
|
Scooter |
|
Rating
|
3.3 View the detailed rating of value for money, design and look, reliability, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
49.4 ccm (3.01 cubic inches) |
|
Engine type
|
Single cylinder, two-stroke |
|
Power output
|
3.8 HP (2.7 kW)) @ 6500 RPM |
|
Top speed
|
80.0 km/h (49.7 mph) |
|
Max RPM
|
8500 |
|
Compression
|
13.7:1 |
|
Fuel system
|
Carburettor. Dell´Orto PHVA 12 |
|
Cooling system
|
Air |
|
Gearbox
|
Automatic |
|
Transmission type
|
Belt (final drive) |
|
Clutch
|
Centrifuge |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Oil forks |
|
Front tire
|
80/80-1443 |
|
Rear tire
|
80/80-1443 |
|
Front brakes
|
Expanding brake (drum brake) |
|
Diameter
|
60 mm (2.4 inches) |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Diameter
|
60 mm (2.4 inches) |
|
Physical measures and capacities |
|
Dry weight
|
68.0 kg (149.9 pounds) |
|
Weight incl. oil, gas, etc
|
72.0 kg (158.7 pounds) |
|
Power/weight ratio
|
0.0551 HP/kg |
|
Front percentage of weight
|
30.0 |
|
Rear percentage of weight
|
70.0 |
|
Fuel capacity
|
5.00 litres (1.32 US gallons) |
|
Reserve fuel capacity
|
1.00 litres (0.26 US gallons) |
|
Other specifications |
|
Color options
|
Red, Yellow, Black, Blue, White- |
|
Starter
|
Electric & kick |
