| Piaggio's profilation of this bike |
| Carnaby will surprise you
every time you go for a ride.
Take its innovative shaped
front lights or the spacious
under-seat bay, big enough
to hold a jet helmet, with
two side pockets for smaller
objects. Then there is the
Easy box: a new integrated
top box designed to hold two
jet helmets, with a quick and
easy locking system operated
by the scooter’s ignition
key. And the Easy cover: an
innovative fold-away leg cover
that can be used to channel
warm air from the radiator,
making Carnaby a pleasure to
ride even in the cold
winter months. |
|
General information |
|
Model
|
Piaggio Carnaby 125 |
|
Model year
|
2008 |
|
Category
|
Scooter |
|
Rating
|
2.9 View the detailed rating of value for money, design and look, reliability, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
124.0 ccm (7.57 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Bore x stroke
|
67.0 x 48.6 mm (2.6 x 1.9 inches) |
|
Fuel system
|
Carburettor |
|
Ignition
|
CDI with variable ignition mapping |
|
Cooling system
|
Liquid |
|
Gearbox
|
Automatic |
|
Clutch
|
Dry automatic centrifugal |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Single cradle in high-strength double steel tube |
|
Front suspension
|
Telescopic hydraulic fork, Ø 35 mm stanchions |
|
Front wheel travel
|
104 mm (4.1 inches) |
|
Rear suspension
|
Two dual-effect hydraulic shock absorbers with spring preload |
|
Rear wheel travel
|
90 mm (3.5 inches) |
|
Front tire
|
110/70-16 |
|
Rear tire
|
130/70-16 |
|
Front brakes
|
Single disc. stainless steel disc |
|
Diameter
|
260 mm (10.2 inches) |
|
Rear brakes
|
Single disc. stainless steel disc |
|
Diameter
|
260 mm (10.2 inches) |
|
Physical measures and capacities |
|
Weight incl. oil, gas, etc
|
146.0 kg (321.9 pounds) |
|
Seat height
|
790 mm (31.1 inches) If adjustable, lowest setting. |
|
Overall length
|
2000 mm (78.7 inches) |
|
Overall width
|
740 mm (29.1 inches) |
|
Wheelbase
|
1365 mm (53.7 inches) |
|
Fuel capacity
|
9.00 litres (2.38 US gallons) |
|
Other specifications |
|
Color options
|
Cometa Yellow, Graphite Black |
|
Starter
|
Electric |
