General information |
|
Model
|
MV Agusta F4 R |
|
Year model
|
2013 |
|
Type
|
Sport |
| Price as new | Euro 18990. MSRP depends on country, taxes, accessories, etc. |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Engine size
|
998.0 ccm (60.90 cubic inches) |
|
Type of engine
|
In-line four, four-stroke |
|
Engine details
|
Radial valve |
|
Effect
|
195.0 HP (142.3 kW)) @ 13400 RPM |
|
Torque
|
110.8 Nm (11.3 kgf-m or 81.7 ft.lbs) @ 9600 RPM |
|
Top speed
|
291.2 km/h (180.9 mph) |
|
Compression
|
13.4:1 |
|
Bore x stroke
|
79.0 x 50.9 mm (3.1 x 2.0 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Injection |
|
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
|
Ignition
|
Integrated ignition - injection system MVICS (Motor and Vehicle Integrated Control System) with eight injectors Engine control unit Eldor EM2.0, throttle body full drive by wire Mikuni, pencil-coil with ion-sensing technology, control of detonation and |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Wet, multi-disc with back torque limiting device |
|
Driveline
|
6-speed constant mesh |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
CrMo Steel Tubular Trellis. Aluminium alloy swing arm. |
|
Trail
|
100 mm (4.0 inches) |
|
Front suspension
|
Marzocchi “UPSIDE - DOWN” telescopic hydraulic fork with adjustable rebound-compression damping and external spring preload |
|
Front wheel travel
|
120 mm (4.7 inches) |
|
Rear suspension
|
Adjustable monoshock with high and low speed compression settings |
|
Rear wheel travel
|
120 mm (4.7 inches) |
|
Front tire
|
120/70-ZR17 |
|
Rear tire
|
200/55-ZR17 |
|
Front brakes
|
Double disc. Brembo radial-type, single-piece with 4 pistons |
|
Diameter
|
320 mm (12.6 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
210 mm (8.3 inches) |
|
Wheels
|
Forged aluminium alloy rims |
|
Physical measures and capacities |
|
Dry weight
|
191.0 kg (421.1 pounds) |
|
Power/weight ratio
|
1.0209 HP/kg |
|
Seat height
|
830 mm (32.7 inches) If adjustable, lowest setting. |
|
Overall length
|
2115 mm (83.3 inches) |
|
Overall width
|
750 mm (29.5 inches) |
|
Ground clearance
|
115 mm (4.5 inches) |
|
Wheelbase
|
1430 mm (56.3 inches) |
|
Fuel capacity
|
17.00 litres (4.49 US gallons) |
|
Other specifications |
|
Color options
|
White, Red/Silver |
|
Starter
|
Electric |
|
Electrical
|
12 V - 8.6 Ah battery. Alternator 350 W at 5000 r.p.m. |
