| Motobi's profilation of this bike |
| Zanzani developed his own process for plasma spraying aluminium disc rotors with iron to produce a far lighter disc brake package than the steel or cast iron discs then commercially available. These discs offered notable benefits in terms of reducing unsprung weight and gyroscopic effect. His brakes became ubiquitous components on GP racers in the smaller classes, winning no less than 24 world championships. |
|
General information |
|
Motorcycle name
|
Motobi Zanzani 250 6 Tiranti |
|
Year model
|
2012 |
|
Type
|
Classic |
| Price as new | Euro 8500. MSRP depends on country, taxes, accessories, etc. |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Engine size
|
249.0 ccm (15.19 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Engine details
|
Manufactured to original drawings, Steel valve , steel retainer, R and D valve springs. |
|
Compression
|
11.0:1 |
|
Bore x stroke
|
75.0 x 57.0 mm (3.0 x 2.2 inches) |
|
Valves per cylinder
|
2 |
|
Fuel system
|
Carburettor. Dell´Orto PHF carburetor with horizontal conversion |
|
Fuel control
|
Overhead Cams (OHC) |
|
Ignition
|
Crane cams electronic ignition/Helotronik |
|
Lubrication system
|
Oil pump |
|
Cooling system
|
Air |
|
Gearbox
|
5-speed |
|
Transmission type
|
Chain (final drive) |
|
Driveline
|
Constant mesh |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Zanzani racing frame |
|
Front suspension
|
Ceriani fork |
|
Rear suspension
|
Work shocks, aluminium |
|
Front tire
|
2.78-18 |
|
Rear tire
|
110/80-18 |
|
Front brakes
|
Single disc. Fontana 4LS Magnesium |
|
Diameter
|
210 mm (8.3 inches) |
|
Rear brakes
|
Single disc. OEM 2LS |
|
Diameter
|
160 mm (6.3 inches) |
|
Wheels
|
Front and rear Akront aluminum rims |
|
Physical measures and capacities |
|
Dry weight
|
101.0 kg (222.7 pounds) |
|
Weight incl. oil, gas, etc
|
117.0 kg (257.9 pounds) |
|
Overall length
|
1920 mm (75.6 inches) |
|
Ground clearance
|
195 mm (7.7 inches) |
|
Wheelbase
|
1310 mm (51.6 inches) |
|
Fuel capacity
|
16.00 litres (4.23 US gallons) |
|
Oil capacity
|
1.50 litres (1.59 US quarts) |
|
Other specifications |
|
Color options
|
Red/white, gray |
|
Starter
|
Electric |
|
Comments
|
Made by Primo Zanzani, Italy. |
