Moto Morini's profilation of this bike |
|
General information |
Motorcycle name
|
Moto Morini Granpasso 1200 |
Year of manufacture
|
2009 |
Type
|
Allround |
Rating
|
3.5 Check out the detailed rating of reliability, maintenance costs, value for money, etc. Compare with any other motorcycle. |
Engine and transmission |
Engine size
|
1187.0 ccm (72.43 cubic inches) |
Type of engine
|
V2, four-stroke |
Output
|
118.0 HP (86.1 kW)) @ 8500 RPM |
Torque
|
103.6 Nm (10.6 kgf-m or 76.4 ft.lbs) @ 7000 RPM |
Compression
|
12.5:1 |
Bore x stroke
|
107.0 x 66.0 mm (4.2 x 2.6 inches) |
Valves per cylinder
|
4 |
Fuel system
|
Injection. I.A.W. |
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
Cooling system
|
Liquid |
Gearbox
|
6-speed |
Transmission type
|
Chain (final drive) |
Clutch
|
Multiple-plate clutch in oil bath with antiskipping system and radial master-cylinder |
Exhaust system
|
Sport Termignoni with double silencer, 3-way catalytic converter and oxygen sensor. Euro 3. |
Chassis, suspension, brakes and wheels |
Frame type
|
High-strength steel tube trellis frame |
Rake (fork angle)
|
26.5° |
Trail
|
135 mm (5.3 inches) |
Front suspension
|
Marzocchi upside down |
Front wheel travel
|
190 mm (7.5 inches) |
Rear suspension
|
Ohlins shock absorber |
Rear wheel travel
|
200 mm (7.9 inches) |
Front tire
|
110/80-R19 |
Rear tire
|
150/70-R17 |
Front brakes
|
Double disc. Bremo |
Diameter
|
298 mm (11.7 inches) |
Rear brakes
|
Single disc. Bremo |
Diameter
|
255 mm (10.0 inches) |
Physical measures and capacities |
Dry weight
|
210.0 kg (463.0 pounds) |
Power/weight ratio
|
0.5619 HP/kg |
Seat height
|
875 mm (34.4 inches) If adjustable, lowest setting. |
Overall length
|
2170 mm (85.4 inches) |
Overall width
|
850 mm (33.5 inches) |
Ground clearance
|
200 mm (7.9 inches) |
Wheelbase
|
1505 mm (59.3 inches) |
Fuel capacity
|
27.00 litres (7.13 US gallons) |
Reserve fuel capacity
|
5.50 litres (1.45 US gallons) |
Other specifications |
Color options
|
Black/grey, red/gray, white/black |
Update specs | Report missing specs or required updates. |
Further information |
Insurance costs | Compare US insurance quotes from the nation's top providers. |
Parts finder |
Check out our overview of motorcycle webshops at Bikez.info. |
Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
Ask questions | Join the 09 Moto Morini Granpasso 1200 discussion group or the general Moto Morini discussion group. |
Related bikes | List related bikes for comparison of specs. |
|
Rating sample for this Moto Morini bike
|
Racing track capabilities for the 2009 Moto Morini Granpasso 1200:
(47.6 out of 100)
