| Moto Morini's profilation of this bike |
| The Scrambler was invented in the 1960s to interpret the thirst for freedom and independence of a generation. Many years down the road, it still maintains its original allure. The aesthetics evoke the glory years that built the legend of the Scrambler, but they also reflect an absolutely modern motorbike with a simplicity and attention to details. |
|
General information |
|
Model name
|
Moto Morini Corsaro 1200 Scrambler |
|
Model year
|
2008 |
|
Category
|
Naked bike |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Displacement
|
1187.0 ccm (72.43 cubic inches) |
|
Engine type
|
V2, four-stroke |
|
Power output
|
138.1 HP (100.8 kW)) @ 8500 RPM |
|
Torque
|
123.0 Nm (12.5 kgf-m or 90.7 ft.lbs) @ 6700 RPM |
|
Bore x stroke
|
107.0 x 66.0 mm (4.2 x 2.6 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Injection. Magneti Marelli |
|
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
|
Cooling system
|
Liquid |
|
Clutch
|
Multiple-plate clutch in oil bath with antiskipping system and radial master-cylinder |
|
Exhaust system
|
Double silencer, 3-way catalytic converter and oxygen sensor |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Verlicchi high-strength steel tube trellis frame |
|
Front suspension
|
Marzocchi upside-down fully adjustable fork with 50 mm legs |
|
Front wheel travel
|
130 mm (5.1 inches) |
|
Rear suspension
|
With progressive motion and single Sachs shock absorber adjustable in extension, compression and spring pre-charge with singlering-nut.Enhanced piston and stretched counter-spring |
|
Rear wheel travel
|
130 mm (5.1 inches) |
|
Front tire
|
120/70-17 |
|
Rear tire
|
180/55-17 |
|
Front brakes
|
Single disc |
|
Diameter
|
320 mm (12.6 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
220 mm (8.7 inches) |
|
Physical measures and capacities |
|
Dry weight
|
199.6 kg (440.0 pounds) |
|
Power/weight ratio
|
0.6921 HP/kg |
|
Seat height
|
805 mm (31.7 inches) If adjustable, lowest setting. |
|
Wheelbase
|
1440 mm (56.7 inches) |
|
Fuel capacity
|
18.00 litres (4.76 US gallons) |
|
Other specifications |
|
Color options
|
Black/gray metallic, Red/grey met, White metallic/black |
|
Starter
|
Electric |
