General information |
|
Model
|
Moto Guzzi V11 Le Mans Rosso Corsa |
|
Year of manufacture
|
2004 |
|
Type
|
Sport touring |
|
Rating
|
3.5 See the detailed rating of touring capabilities, reliability, accident risk, etc. Compare with any other motorbike. |
|
Engine and transmission |
|
Engine size
|
1064.0 ccm (64.93 cubic inches) |
|
Type of engine
|
V2, four-stroke |
|
Output
|
89.9 HP (65.6 kW)) @ 8200 RPM |
|
Torque
|
94.0 Nm (9.6 kgf-m or 69.3 ft.lbs) @ 5400 RPM |
|
Compression
|
9.8:1 |
|
Bore x stroke
|
92.0 x 80.0 mm (3.6 x 3.1 inches) |
|
Valves per cylinder
|
2 |
|
Fuel system
|
Injection |
|
Fuel control
|
Overhead Cams (OHC) |
|
Cooling system
|
Air |
|
Gearbox
|
6-speed |
|
Transmission type
|
Shaft drive (cardan) (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Monobeam frame |
|
Rake (fork angle)
|
25.0° |
|
Trail
|
103 mm (4.1 inches) |
|
Front suspension
|
Ohlins USD fork, 43 mm compression/extension preload adjustable |
|
Front wheel travel
|
120 mm (4.7 inches) |
|
Rear suspension
|
Cantilever swing arm with Ohlins mono shock compression/extension/preload adjustable |
|
Rear wheel travel
|
128 mm (5.0 inches) |
|
Front tire
|
120/70-ZR17 |
|
Rear tire
|
180/55-ZR17 |
|
Front brakes
|
Double disc |
|
Diameter
|
320 mm (12.6 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
282 mm (11.1 inches) |
|
Physical measures and capacities |
|
Dry weight
|
226.0 kg (498.2 pounds) |
|
Power/weight ratio
|
0.3976 HP/kg |
|
Seat height
|
800 mm (31.5 inches) If adjustable, lowest setting. |
|
Overall height
|
1210 mm (47.6 inches) |
|
Overall length
|
2150 mm (84.6 inches) |
|
Overall width
|
785 mm (30.9 inches) |
|
Ground clearance
|
178 mm (7.0 inches) |
|
Wheelbase
|
1490 mm (58.7 inches) |
|
Fuel capacity
|
20.70 litres (5.47 US gallons) |
|
Reserve fuel capacity
|
5.00 litres (1.32 US gallons) |
|
Other specifications |
|
Color options
|
Rosso Corsa |
|
Comments
|
V11 Le Mans Rosso Corsa -Sport Touring redefined. The latest 90ยบ V-Twin with added crossover pipe and increased compression ratio to 9.8:1. Brembo Gold Series brakes and Ohlins suspension. Admire the checkered flag graphics in the traditional red finish with a carbon fiber front fender-there's nothing subtle about this long distance muscle machine. Add optional Moto Guzzi soft side bags and tank bag and you've got a comfortable Sport Touring Bike that will get you to your favorite track day in style.
|
