General information |
|
Model
|
Moto Guzzi Nevada 750 |
|
Year
|
2004 |
|
Category
|
Custom / cruiser |
|
Rating
|
3.6 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
744.0 ccm (45.40 cubic inches) |
|
Engine type
|
V2, four-stroke |
|
Power
|
45.6 HP (33.3 kW)) @ 6600 RPM |
|
Torque
|
77.3 Nm (7.9 kgf-m or 57.0 ft.lbs) @ 3000 RPM |
|
Compression
|
9.6:1 |
|
Bore x stroke
|
80.0 x 74.0 mm (3.1 x 2.9 inches) |
|
Valves per cylinder
|
2 |
|
Fuel system
|
Carburettor |
|
Fuel control
|
Overhead Cams (OHC) |
|
Cooling system
|
Air |
|
Gearbox
|
5-speed |
|
Transmission type
|
Shaft drive (cardan) (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Detachable tubular duplex cradle |
|
Rake (fork angle)
|
28.0° |
|
Trail
|
134 mm (5.3 inches) |
|
Front suspension
|
Marzocchi 40 mm hydraulic telescopic fork |
|
Front wheel travel
|
136 mm (5.4 inches) |
|
Rear suspension
|
Swing arm in light cast alloy with two dampers, spring adjustable for pre-load and rebound |
|
Rear wheel travel
|
75 mm (3.0 inches) |
|
Front tire
|
100/90-V18 |
|
Rear tire
|
130/90-V16 |
|
Front brakes
|
Single disc |
|
Diameter
|
320 mm (12.6 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
260 mm (10.2 inches) |
|
Physical measures and capacities |
|
Dry weight
|
176.0 kg (388.0 pounds) |
|
Power/weight ratio
|
0.2590 HP/kg |
|
Seat height
|
770 mm (30.3 inches) If adjustable, lowest setting. |
|
Overall length
|
2205 mm (86.8 inches) |
|
Overall width
|
875 mm (34.4 inches) |
|
Ground clearance
|
190 mm (7.5 inches) |
|
Wheelbase
|
1482 mm (58.3 inches) |
|
Fuel capacity
|
14.00 litres (3.70 US gallons) |
|
Reserve fuel capacity
|
4.00 litres (1.06 US gallons) |
|
Other specifications |
|
Color options
|
Beige sabbia/Grigio platino, Grigio iron/nero |
