General information |
|
Motorcycle name
|
Moto Guzzi Griso 1200 8V |
|
Model year
|
2012 |
|
Category
|
Naked bike |
| Price as new | US$ 14290. MSRP depends on country, taxes, accessories, etc. |
|
Rating
|
3.2 See the detailed rating of engine performance, design and look, accident risk, etc. Compare with any other motorcycle. |
|
Engine and transmission |
|
Displacement
|
1151.0 ccm (70.23 cubic inches) |
|
Engine type
|
V2, four-stroke |
|
Engine details
|
V 90 twin |
|
Power output
|
110.0 HP (80.3 kW)) @ 7500 RPM |
|
Torque
|
108.0 Nm (11.0 kgf-m or 79.7 ft.lbs) @ 6400 RPM |
|
Compression
|
11.0:1 |
|
Bore x stroke
|
95.0 x 81.2 mm (3.7 x 3.2 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Injection. Weber-Marelli |
|
Fuel control
|
Overhead Valves (OHV) |
|
Ignition
|
Inductive discharge, digitally controlled, electronic twin spark ignition |
|
Cooling system
|
Air |
|
Gearbox
|
6-speed |
|
Transmission type
|
Shaft drive (cardan) (final drive) |
|
Clutch
|
Single plate with integrated flexible couplings |
|
Driveline
|
Primary drive: Helicoidal gears, ratio 26/35 = 1 : 1.346. Final drive CA.R.C reactive drive; double universal joint with floating bevel gear, ratio 12/44 = 1 : 3,666 |
|
Emission details
|
Three way catalyser and Lambda probe oxygen sensor |
|
Exhaust system
|
Stainless steel two-into-one 3-way catalysed with Lambda probe. |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Double cradle, in high tensile strength tubular steel |
|
Rake (fork angle)
|
26.3° |
|
Trail
|
108 mm (4.3 inches) |
|
Front suspension
|
Upside down fork, fully adjustable in spring preload and compression and rebound damping |
|
Front wheel travel
|
120 mm (4.7 inches) |
|
Rear suspension
|
Progressive single swingarm, fully adjustable monoshock with separate gas reservoir (spring preload and hydraulic for rebound and compression). |
|
Rear wheel travel
|
110 mm (4.3 inches) |
|
Front tire
|
120/70-ZR17 |
|
Rear tire
|
180/55-ZR17 |
|
Front brakes
|
Double disc. Stainless steel wave discs, radial calipers with 4 opposed pistons. |
|
Diameter
|
320 mm (12.6 inches) |
|
Rear brakes
|
Single disc. Fixed stainless steel disc, floating caliper with 2 parallel pistons. |
|
Diameter
|
282 mm (11.1 inches) |
|
Wheels
|
Three-spoked aluminum alloy |
|
Physical measures and capacities |
|
Dry weight
|
222.0 kg (489.4 pounds) |
|
Power/weight ratio
|
0.4955 HP/kg |
|
Seat height
|
800 mm (31.5 inches) If adjustable, lowest setting. |
|
Overall height
|
1070 mm (42.1 inches) |
|
Overall length
|
2260 mm (89.0 inches) |
|
Overall width
|
830 mm (32.7 inches) |
|
Ground clearance
|
185 mm (7.3 inches) |
|
Wheelbase
|
1554 mm (61.2 inches) |
|
Fuel capacity
|
16.70 litres (4.41 US gallons) |
|
Reserve fuel capacity
|
3.30 litres (0.87 US gallons) |
|
Other specifications |
|
Color options
|
Guzzi Black |
|
Starter
|
Electric |
