General information |
|
Motorcycle name
|
Mondial 125 ZNU |
|
Year model
|
2012 |
|
Type
|
Scooter |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Engine size
|
124.6 ccm (7.60 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Torque
|
7.0 Nm (0.7 kgf-m or 5.2 ft.lbs) @ 5500 RPM |
|
Compression
|
9.2:1 |
|
Bore x stroke
|
52.4 x 57.8 mm (2.1 x 2.3 inches) |
|
Fuel system
|
Carburettor |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Ignition
|
CDI |
|
Cooling system
|
Air |
|
Gearbox
|
Automatic |
|
Transmission type
|
Belt (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Hydraulic Front Fork |
|
Rear suspension
|
Single Shock |
|
Front tire
|
3.50-10 |
|
Rear tire
|
3.50-10 |
|
Front brakes
|
Single disc |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Physical measures and capacities |
|
Dry weight
|
97.0 kg (213.8 pounds) |
|
Overall height
|
1090 mm (42.9 inches) |
|
Overall length
|
1891 mm (74.4 inches) |
|
Overall width
|
872 mm (34.3 inches) |
|
Wheelbase
|
1235 mm (48.6 inches) |
|
Fuel capacity
|
4.20 litres (1.11 US gallons) |
|
Other specifications |
|
Color options
|
Gray, black |
|
Starter
|
Electric & kick |
