| MBK's profilation of this bike |
| The Stunt Naked frame is very solid / shatterproof. It has tough protective pads all over it. |
|
General moped information |
|
Model
|
MBK Stunt Naked |
|
Year of manufacture
|
2009 |
|
Type
|
Scooter |
|
Rating
|
3.6 View the detailed rating of value for money, design and look, reliability, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
49.9 ccm (3.04 cubic inches) |
|
Type of engine
|
Single cylinder, two-stroke |
|
Output
|
3.6 HP (2.6 kW)) @ 6800 RPM |
|
Torque
|
4.0 Nm (0.4 kgf-m or 3.0 ft.lbs) @ 5000 RPM |
|
Compression
|
11.2:1 |
|
Bore x stroke
|
40.0 x 39.2 mm (1.6 x 1.5 inches) |
|
Ignition
|
CDI |
|
Lubrication system
|
Separate lubrication |
|
Cooling system
|
Air |
|
Gearbox
|
Automatic |
|
Transmission type
|
Belt (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Telescopic fork |
|
Front wheel travel
|
80 mm (3.1 inches) |
|
Rear suspension
|
Unit swing |
|
Rear wheel travel
|
60 mm (2.4 inches) |
|
Front tire
|
120/80-12 |
|
Rear tire
|
130/90-10 |
|
Front brakes
|
Single disc |
|
Diameter
|
190 mm (7.5 inches) |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Diameter
|
110 mm (4.3 inches) |
|
Physical measures and capacities |
|
Dry weight
|
267.0 kg (588.6 pounds) |
|
Weight incl. oil, gas, etc
|
82.0 kg (180.8 pounds) |
|
Power/weight ratio
|
0.0136 HP/kg |
|
Seat height
|
787 mm (31.0 inches) If adjustable, lowest setting. |
|
Overall length
|
1785 mm (70.3 inches) |
|
Overall width
|
711 mm (28.0 inches) |
|
Ground clearance
|
155 mm (6.1 inches) |
|
Wheelbase
|
1202 mm (47.3 inches) |
|
Fuel capacity
|
5.50 litres (1.45 US gallons) |
|
Oil capacity
|
1.40 litres (1.48 US quarts) |
|
Other specifications |
|
Starter
|
Electric & kick |
