| MBK's profilation of this bike |
| With the new high-wheel Oceo, getting round town is a pleasure. Every aspect of this scooter has been designed to make your daily commute more rapid and more comfortable. |
|
General information |
|
Model
|
MBK Oceo 125 |
|
Year of manufacture
|
2012 |
|
Type
|
Scooter |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Engine size
|
125.0 ccm (7.63 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Output
|
12.3 HP (9.0 kW)) @ 7500 RPM |
|
Torque
|
11.9 Nm (1.2 kgf-m or 8.8 ft.lbs) @ 7250 RPM |
|
Compression
|
11.0:1 |
|
Bore x stroke
|
52.0 x 58.7 mm (2.0 x 2.3 inches) |
|
Fuel system
|
Injection |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Ignition
|
TCI |
|
Lubrication system
|
Force-feed lubrication,Wet sump |
|
Cooling system
|
Liquid |
|
Gearbox
|
Automatic |
|
Transmission type
|
Shaft drive (cardan) (final drive) |
|
Clutch
|
Dry, centrifugal, shoe |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Underbone |
|
Rake (fork angle)
|
23.0° |
|
Trail
|
84 mm (3.3 inches) |
|
Front suspension
|
Telescopic |
|
Front wheel travel
|
100 mm (3.9 inches) |
|
Rear suspension
|
Unit swing |
|
Rear wheel travel
|
92 mm (3.6 inches) |
|
Front tire
|
100/80-16 |
|
Rear tire
|
120/80-16 |
|
Front brakes
|
Single disc |
|
Diameter
|
267 mm (10.5 inches) |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Physical measures and capacities |
|
Dry weight
|
159.0 kg (350.5 pounds) |
|
Weight incl. oil, gas, etc
|
142.0 kg (313.1 pounds) |
|
Power/weight ratio
|
0.0776 HP/kg |
|
Seat height
|
785 mm (30.9 inches) If adjustable, lowest setting. |
|
Overall height
|
1135 mm (44.7 inches) |
|
Overall length
|
1990 mm (78.3 inches) |
|
Overall width
|
690 mm (27.2 inches) |
|
Ground clearance
|
140 mm (5.5 inches) |
|
Wheelbase
|
1385 mm (54.5 inches) |
|
Fuel capacity
|
8.00 litres (2.11 US gallons) |
|
Oil capacity
|
1.20 litres (1.27 US quarts) |
|
Other specifications |
|
Color options
|
Black, white |
|
Starter
|
Electric |
|
Electrical
|
12V 6.5AH(10H) battery. |
