| Malaguti's profilation of this bike |
| A successful sports, never growing, old design: that is Phantom Max 125, a proper Super-sport scooter, for youngsters looking for power and quickness, performance and handiness in the same vehicle. |
|
General information |
|
Model name
|
Malaguti Phantom Max 125 |
|
Model year
|
2007 |
|
Category
|
Scooter |
|
Rating
|
3.7 View the detailed rating of value for money, design and look, reliability, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
124.0 ccm (7.57 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Power output
|
13.4 HP (9.8 kW)) @ 9500 RPM |
|
Torque
|
10.5 Nm (1.1 kgf-m or 7.7 ft.lbs) @ 8000 RPM |
|
Compression
|
11.0:1 |
|
Bore x stroke
|
53.7 x 54.8 mm (2.1 x 2.2 inches) |
|
Cooling system
|
Liquid |
|
Gearbox
|
Automatic |
|
Transmission type
|
Belt (final drive) |
|
Clutch
|
Automatic centrifugal dry clutch |
|
Exhaust system
|
Catalyst exhaust system |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Hydraulic fork |
|
Front wheel travel
|
90 mm (3.5 inches) |
|
Rear suspension
|
Swinging engine and two hydraulic shock absorbers |
|
Rear wheel travel
|
80 mm (3.1 inches) |
|
Front tire
|
130/70-13 |
|
Rear tire
|
130/60-13 |
|
Front brakes
|
Single disc |
|
Diameter
|
220 mm (8.7 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
220 mm (8.7 inches) |
|
Physical measures and capacities |
|
Dry weight
|
131.0 kg (288.8 pounds) |
|
Power/weight ratio
|
0.1024 HP/kg |
|
Seat height
|
790 mm (31.1 inches) If adjustable, lowest setting. |
|
Overall length
|
1980 mm (78.0 inches) |
|
Wheelbase
|
1400 mm (55.1 inches) |
|
Other specifications |
|
Color options
|
Silver, Dark Blue/Titanium,Blue Black, Velvet Black |
|
Starter
|
Electric |
