| Malaguti's profilation of this bike |
| Drakon 50 looks modern and technically superb.
A multifunction on board computer includes tachometer, speedometer, partial and total odometer, running max and average speed , acceleration timing, battery voltage, timepiece, chronometer and coolant temperature: a real onboard computer for the most demanding youngsters to have fun!
|
| General moped information |
|---|
| Model | Malaguti Drakon NKD 50 |
| Year | 2007 |
| Category | Naked bike |
| Rating | 3.6 See the detailed rating of engine performance, design and look, accident risk, etc. Compare with any other motorcycle. |
| Engine and transmission |
|---|
| Displacement | 50.0 ccm (3.05 cubic inches) |
| Engine type | Single cylinder, four-stroke |
| Compression | 12.0:1 |
| Bore x stroke | 40.3 x 39.0 mm (1.6 x 1.5 inches) |
| Valves per cylinder | 4 |
| Fuel system | Carburettor. Dell´Orto PHBN16 |
| Fuel control | Single Overhead Cams (SOHC) |
| Lubrication system | Separate lubrication by automatic mixing pump |
| Cooling system | Liquid |
| Gearbox | 6-speed |
| Clutch | Multi-disc oil bathed clutch |
| Chassis, suspension, brakes and wheels |
|---|
| Front tire | 100/80-17 |
| Rear tire | 130/70-17 |
| Front brakes | Single disc |
| Diameter | 280 mm (11.0 inches) |
| Rear brakes | Single disc |
| Diameter | 218 mm (8.6 inches) |
| Physical measures and capacities |
|---|
| Dry weight | 112.0 kg (246.9 pounds) |
| Overall length | 1970 mm (77.6 inches) |
| Overall width | 755 mm (29.7 inches) |
| Wheelbase | 1325 mm (52.2 inches) |
| Fuel capacity | 10.00 litres (2.64 US gallons) |
| Reserve fuel capacity | 1.20 litres (0.32 US gallons) |
| Other specifications |
|---|
| Color options | Black, Yellow/black |
| Starter | Electric |
| Comments | A special Dicati Course version ia available. |
