General moped information |
|
Model name
|
Macbor XC 515 R 6v |
|
Year of manufacture
|
2004 |
|
Type
|
Minibike, cross |
|
Rating
|
3.5 See the detailed rating of the fun-factor, engine performance, racing track capabilities, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
49.9 ccm (3.05 cubic inches) |
|
Type of engine
|
Single cylinder, two-stroke |
|
Bore x stroke
|
39.0 x 41.8 mm (1.5 x 1.6 inches) |
|
Fuel system
|
Carburettor |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Hydraulic |
|
Front wheel travel
|
190 mm (7.5 inches) |
|
Rear suspension
|
Hydraulic shock absorber |
|
Rear wheel travel
|
200 mm (7.9 inches) |
|
Front brakes
|
Single disc |
|
Rear brakes
|
Single disc |
|
Physical measures and capacities |
|
Dry weight
|
55.0 kg (121.3 pounds) |
|
Seat height
|
740 mm (29.1 inches) If adjustable, lowest setting. |
|
Overall height
|
910 mm (35.8 inches) |
|
Overall length
|
1580 mm (62.2 inches) |
|
Overall width
|
700 mm (27.6 inches) |
|
Wheelbase
|
1110 mm (43.7 inches) |
|
Fuel capacity
|
3.90 litres (1.03 US gallons) |
|
Other specifications |
