| LML's profilation of this bike |
| The Gamma-9 engine and its rapid turbulence combustion chamber is fitted with a microprocessor for accurate ignition timing and uses the principle of computational flow dynamics. |
|
General information |
|
Model name
|
LML Graptor |
|
Year of manufacture
|
2010 |
|
Type
|
Scooter |
|
Rating
|
3.3 View the detailed rating of value for money, design and look, reliability, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
150.8 ccm (9.20 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Output
|
13.5 HP (9.9 kW)) @ 8000 RPM |
|
Fuel system
|
Carburettor |
|
Ignition
|
CDI |
|
Cooling system
|
Air |
|
Gearbox
|
5-speed |
|
Transmission type
|
Chain (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Front tire
|
2.75-18 |
|
Rear tire
|
3.00-18 |
|
Front brakes
|
Single disc |
|
Diameter
|
180 mm (7.1 inches) |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Diameter
|
130 mm (5.1 inches) |
|
Physical measures and capacities |
|
Dry weight
|
136.0 kg (299.8 pounds) |
|
Power/weight ratio
|
0.0993 HP/kg |
|
Ground clearance
|
170 mm (6.7 inches) |
|
Wheelbase
|
1280 mm (50.4 inches) |
|
Fuel capacity
|
8.00 litres (2.11 US gallons) |
|
Other specifications |
|
Color options
|
Black, Maroon, Silver, Blue. |
|
Comments
|
LML is an abbreviataion of Lohia Machines Limited in India. Available as an ES model with electric starter and a KS version with a Kick Start. |
| Update specs | Report missing specs or required updates. |
|
Further information |
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Parts finder |
Check out our overview of motorcycle webshops at Bikez.info. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 10 LML Graptor discussion group or the general LML discussion group. |
| Related bikes | List related bikes for comparison of specs. |
|
|
|
Rating sample for this LML bike
|
Racing track capabilities for the 2010 LML Graptor:
 (52.5 out of 100)
Click here for complete rating. You can also compare bikes.
|
|
