Linhai's profilation of this bike |
This brand new, eye catching vehicle ATV Linhai has had its design renewed and it’s now even more aggressive. |
General information |
Model name
|
Linhai ATV Dragon Fly 400 |
Year of manufacture
|
2010 |
Type
|
ATV |
Rating
|
3.4 Check out the detailed rating of reliability, maintenance costs, value for money, etc. Compare with any other motorcycle. |
Engine and transmission |
Engine size
|
352.0 ccm (21.48 cubic inches) |
Type of engine
|
Single cylinder, four-stroke |
Fuel system
|
Carburettor |
Lubrication system
|
Wet sump |
Gearbox
|
Automatic |
Transmission type
|
Shaft drive (cardan) (final drive) |
Chassis, suspension, brakes and wheels |
Front suspension
|
Independent - mac pherson |
Rear suspension
|
Independent- double triangles superimposed |
Front tire
|
25/8-12 |
Rear tire
|
25/10-12 |
Front brakes
|
Single disc |
Rear brakes
|
Single disc |
Physical measures and capacities |
Dry weight
|
330.0 kg (727.5 pounds) |
Overall height
|
1221 mm (48.1 inches) |
Overall length
|
2110 mm (83.1 inches) |
Overall width
|
1114 mm (43.9 inches) |
Wheelbase
|
1280 mm (50.4 inches) |
Other specifications |
Color options
|
White, red |
Starter
|
Electric & kick |
Comments
|
H/L/R 4x4 |
Update specs | Report missing specs or required updates. |
Further information |
Insurance costs | Compare US insurance quotes from the nation's top providers. |
Parts finder |
Check out our overview of motorcycle webshops at Bikez.info. |
Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
Ask questions | Join the 10 Linhai ATV Dragon Fly 400 discussion group or the general Linhai discussion group. |
Related bikes | List related bikes for comparison of specs. |
|
Rating sample for this Linhai bike
|
Engine performance for the 2010 Linhai ATV Dragon Fly 400:
(70.0 out of 100)
Click here for complete rating. You can also compare bikes.
|
|
