| Lem's profilation of this bike |
| You donīt putt around on these bikes - you race them! |
| General moped information |
|---|
| Model: | Lem R3 |
| Year: | 2006 |
| Category: | Minibike, cross |
| Price as new: | US$ 4645. MSRP depend on country, taxes, accessories, etc. |
| Rating: | 3.1 See the detailed rating of the fun-factor, engine performance, racing track capabilities, etc. Compare with any other bike. |
| Engine and transmission |
|---|
| Displacement: | 49.8 ccm (3.04 cubic inches) |
| Engine type: | Single cylinder, two-stroke |
| Power: | 12.8 HP (9.3 kW)) |
| Bore x stroke: | 39.0 x 41.7 mm (1.5 x 1.6 inches) |
| Fuel system: | Carburettor. DellīOrto PHBG 14MS |
| Lubrication system: | Premix |
| Cooling system: | Liquid |
| Gearbox: | 1-speed |
Transmission type,
final drive: | Chain |
| Clutch: | Centrifugal automatic |
| Exhaust system: | Works style racing exhaust w/ rebuildable alloy oval silencer |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type: | ChroMoly oval perimeter frame |
| Front suspension: | Marzocchi dual hydraulic with aluminum triple clamp |
| Rear suspension: | Paioli SX remote hydraulic monoshock with adjustable comp/rebound |
| Front brakes: | Single disc |
| Rear brakes: | Single disc |
| Physical measures and capacities |
|---|
| Dry weight: | 42.0 kg (92.6 pounds) |
| Power/weight ratio: | 0.3048 HP/kg |
| Seat height: | 610 mm (24.0 inches) If adjustable, lowest setting. |
| Ground clearance: | 279 mm (11.0 inches) |
| Wheelbase: | 914 mm (36.0 inches) |
| Fuel capacity: | 3.00 litres (0.79 gallons) |
| Other specifications |
|---|
| Starter: | Kick |
| Comments: | Intended for kids, but racing series. |
