| Lehman Trikes' profilation of this bike |
| The Raider offers straightforward, effortless bodylines sure to please the eye. In addition to the comfortable ride and the well-known stability of the Lehman No-Lean design, it now features a practical trunk to keep items safe and secure. |
|
General information |
|
Model
|
Lehman Trikes Raider Sportster |
|
Year of manufacture
|
2010 |
|
Type
|
Custom / cruiser |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Engine size
|
1202.0 ccm (73.35 cubic inches) |
|
Type of engine
|
V2, four-stroke |
|
Torque
|
98.0 Nm (10.0 kgf-m or 72.3 ft.lbs) @ 3200 RPM |
|
Compression
|
9.7:1 |
|
Bore x stroke
|
88.9 x 96.8 mm (3.5 x 3.8 inches) |
|
Fuel system
|
Injection. Electronic Sequential Port Fuel Injection (ESPFI) |
|
Cooling system
|
Air |
|
Gearbox
|
5-speed |
|
Transmission type
|
Belt (final drive) |
|
Clutch
|
9-plate, wet |
|
Exhaust system
|
Chrome, staggered shorty exhaust with dual mufflers |
|
Chassis, suspension, brakes and wheels |
|
Rake (fork angle)
|
30.0° |
|
Trail
|
119 mm (4.7 inches) |
|
Front suspension
|
39mm fork |
|
Front wheel travel
|
145 mm (5.7 inches) |
|
Rear suspension
|
Coil-over preload dual-adjustable |
|
Rear wheel travel
|
54 mm (2.1 inches) |
|
Front tire
|
MH90-21 |
|
Rear tire
|
150/80-16 |
|
Front brakes
|
Single disc. 2-piston calipers |
|
Diameter
|
292 mm (11.5 inches) |
|
Rear brakes
|
Single disc. Single pistom |
|
Diameter
|
292 mm (11.5 inches) |
|
Physical measures and capacities |
|
Weight incl. oil, gas, etc
|
378.0 kg (833.3 pounds) |
|
Seat height
|
673 mm (26.5 inches) If adjustable, lowest setting. |
|
Overall length
|
1464 mm (57.6 inches) |
|
Overall width
|
1372 mm (54.0 inches) |
|
Ground clearance
|
112 mm (4.4 inches) |
|
Wheelbase
|
1549 mm (61.0 inches) |
|
Fuel capacity
|
17.00 litres (4.49 US gallons) |
|
Other specifications |
|
Starter
|
Electric |
|
Comments
|
Three wheels. Modified Harley-Davidson Sportster. Trunk Volume: 2 cu.ft. (57 L). |
