| Lambretta's profilation of this bike |
| Lambretta LN is not the product of analyses or calculations. It is the product of pure passion. And our production mission - attention to detail – speaks volumes of this. |
|
General information |
|
Model
|
Lambretta LN151 |
|
Year of manufacture
|
2012 |
|
Type
|
Scooter |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Engine size
|
151.0 ccm (9.21 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Output
|
10.3 HP (7.5 kW)) @ 7500 RPM |
|
Torque
|
10.8 Nm (1.1 kgf-m or 8.0 ft.lbs) @ 6000 RPM |
|
Bore x stroke
|
57.4 x 58.2 mm (2.3 x 2.3 inches) |
|
Valves per cylinder
|
2 |
|
Fuel system
|
Carburettor |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Lubrication system
|
Vapor lubrication system, force-feed |
|
Cooling system
|
Air |
|
Gearbox
|
Automatic |
|
Transmission type
|
Belt (final drive) |
|
Driveline
|
CVT / speed variator |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Steel |
|
Front suspension
|
Telescopic hydraulic |
|
Rear suspension
|
Hydraulic monoshock |
|
Front tire
|
110/70-12 |
|
Rear tire
|
120/70-12 |
|
Front brakes
|
Single disc |
|
Diameter
|
190 mm (7.5 inches) |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Physical measures and capacities |
|
Dry weight
|
111.0 kg (244.7 pounds) |
|
Power/weight ratio
|
0.0931 HP/kg |
|
Seat height
|
800 mm (31.5 inches) If adjustable, lowest setting. |
|
Overall height
|
1380 mm (54.3 inches) |
|
Overall length
|
1930 mm (76.0 inches) |
|
Overall width
|
530 mm (20.9 inches) |
|
Fuel capacity
|
6.00 litres (1.59 US gallons) |
|
Other specifications |
|
Color options
|
Milk/Cyan, Milk/Yellow, Milk/Red, Milk/Coral, Milk/green |
|
Starter
|
Electric |
