General moped information |
---|
Model | Kymco Maxxer 50 |
Year | 2009 |
Category | ATV |
Rating | 3.1 Check out the detailed rating of reliability, maintenance costs, value for money, etc. Compare with any other motorcycle. |
Engine and transmission |
---|
Displacement | 49.0 ccm (2.99 cubic inches) |
Engine type | Single cylinder, two-stroke |
Power | 3.9 HP (2.8 kW)) @ 6000 RPM |
Compression | 7.2:1 |
Bore x stroke | 39.0 x 41.0 mm (1.5 x 1.6 inches) |
Fuel system | Carburettor |
Fuel control | Overhead Cams (OHC) |
Ignition | C.D.I. |
Cooling system | Air |
Gearbox | Automatic |
Transmission type | Belt (final drive) |
Clutch | Wet, multiplate |
Chassis, suspension, brakes and wheels |
---|
Frame type | SP pipe |
Front suspension | Single A-Arm |
Front wheel travel | 71 mm (2.8 inches) |
Rear suspension | Unit swing |
Rear wheel travel | 74 mm (2.9 inches) |
Front tire | 16/8-7 |
Rear tire | 16/8-7 |
Front brakes | Expanding brake (drum brake) |
Rear brakes | Expanding brake (drum brake) |
Physical measures and capacities |
---|
Dry weight | 100.0 kg (220.5 pounds) |
Power/weight ratio | 0.0390 HP/kg |
Seat height | 630 mm (24.8 inches) If adjustable, lowest setting. |
Overall height | 900 mm (35.4 inches) |
Overall length | 1385 mm (54.5 inches) |
Overall width | 820 mm (32.3 inches) |
Ground clearance | 75 mm (3.0 inches) |
Wheelbase | 900 mm (35.4 inches) |
Fuel capacity | 6.80 litres (1.80 US gallons) |
Other specifications |
---|
Color options | Yellow |
Starter | Electric & kick |
Comments | Made in Taiwan. |
