General information |
|
Motorcycle name
|
KTM 990 Supermoto R |
|
Year of manufacture
|
2012 |
|
Type
|
Super motard |
|
Rating
|
3.0 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
999.0 ccm (60.96 cubic inches) |
|
Type of engine
|
V2, four-stroke |
|
Engine details
|
75° V arrangement |
|
Output
|
114.0 HP (83.2 kW)) @ 4000 RPM |
|
Torque
|
97.0 Nm (9.9 kgf-m or 71.5 ft.lbs) @ 7000 RPM |
|
Compression
|
11.5:1 |
|
Bore x stroke
|
101.0 x 62.4 mm (4.0 x 2.5 inches) |
|
Fuel system
|
Injection. Keihin EFI |
|
Ignition
|
Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment |
|
Lubrication system
|
Dry-sump lubrication with 2 rotor pumps |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Wet multi-disc clutch / hydraulically operated |
|
Driveline
|
17:41. Primary drive: 35:67. |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Tubular space frame made from chrome molybdenum steel, powder-coated |
|
Rake (fork angle)
|
24.4° |
|
Trail
|
109 mm (4.3 inches) |
|
Front suspension
|
WP Suspension Up Side Down 4860 ROMA PA |
|
Front wheel travel
|
160 mm (6.3 inches) |
|
Rear suspension
|
WP Suspension 4618 BAVP DCC |
|
Rear wheel travel
|
180 mm (7.1 inches) |
|
Front tire
|
120/70-17 |
|
Rear tire
|
180/55-ZR17 |
|
Front brakes
|
Double disc. ABS. Brembo four piston fixed-caliper, radial bolted, brake. |
|
Diameter
|
305 mm (12.0 inches) |
|
Rear brakes
|
Single disc. ABS. two-piston brake caliper; fixed brake disc |
|
Diameter
|
240 mm (9.4 inches) |
|
Physical measures and capacities |
|
Dry weight
|
192.0 kg (423.3 pounds) |
|
Power/weight ratio
|
0.5938 HP/kg |
|
Seat height
|
875 mm (34.4 inches) If adjustable, lowest setting. |
|
Ground clearance
|
195 mm (7.7 inches) |
|
Wheelbase
|
1505 mm (59.3 inches) |
|
Fuel capacity
|
15.00 litres (3.96 US gallons) |
|
Other specifications |
|
Color options
|
Black/orange/white |
|
Starter
|
Electric |
|
Comments
|
Also called KTM 990 SM R. |
