| KTM's profilation of this bike |
| With even more displacement, an electronic fuel injection and a regulated catalytic converter, the 990 Adventure R is now elevated to the highest technical level in matters of safety and emission control, which is now regulated to conform to EURO III standards. |
|
General information |
|
Model name
|
KTM 990 Adventure R |
|
Year
|
2009 |
|
Category
|
Enduro / offroad |
|
Rating
|
3.9 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
999.0 ccm (60.96 cubic inches) |
|
Engine type
|
V2, four-stroke |
|
Power
|
113.3 HP (82.7 kW)) @ 8750 RPM |
|
Torque
|
100.0 Nm (10.2 kgf-m or 73.8 ft.lbs) @ 6750 RPM |
|
Compression
|
11.5:1 |
|
Bore x stroke
|
101.0 x 62.4 mm (4.0 x 2.5 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Injection. Keihin electronic injection |
|
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
|
Ignition
|
Keihin EMS |
|
Lubrication system
|
Pressure lubrication |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Wet multi-disc clutch, operated hydraulically |
|
Exhaust system
|
Twin stainless steel silencer with regulated catalytic converter |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Chromium-Molybdenum trellis frame, powder-coated. Aluminium subframe |
|
Rake (fork angle)
|
26.6° |
|
Trail
|
119 mm (4.7 inches) |
|
Front suspension
|
WP USD, 48 mm |
|
Front wheel travel
|
265 mm (10.4 inches) |
|
Rear suspension
|
WP monoshock PDS with hydraulic spring preload |
|
Rear wheel travel
|
265 mm (10.4 inches) |
|
Front tire
|
90/90-21 |
|
Rear tire
|
150/70-18 |
|
Front brakes
|
Double disc. 2 x Brembo two piston, floating caliper, floating brake disc. |
|
Diameter
|
300 mm (11.8 inches) |
|
Rear brakes
|
Single disc. Brembo two piston, floating caliper, floating brake disc. |
|
Diameter
|
240 mm (9.4 inches) |
|
Physical measures and capacities |
|
Dry weight
|
207.0 kg (456.4 pounds) |
|
Power/weight ratio
|
0.5474 HP/kg |
|
Seat height
|
915 mm (36.0 inches) If adjustable, lowest setting. |
|
Ground clearance
|
316 mm (12.4 inches) |
|
Wheelbase
|
1570 mm (61.8 inches) |
|
Fuel capacity
|
19.50 litres (5.15 US gallons) |
|
Other specifications |
|
Starter
|
Electric |
| Update specs | Report missing specs or required updates. |
|
Further information |
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Parts finder |
Check out our overview of motorcycle webshops at Bikez.info. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 09 KTM 990 Adventure R discussion group or the general KTM discussion group. |
| Related bikes | List related bikes for comparison of specs. |
|
|
|
Rating sample for this KTM bike
|
Touring capabilities for the 2009 KTM 990 Adventure R:
 (70.8 out of 100)
Click here for complete rating. You can also compare bikes.
|
|
