| KTM's profilation of this bike |
| The new, high quality, chrome-molybdenum steel frame and the redesigned, bolt-on, lightweight aluminium subframe have been further refined in many details. As on the full-size bikes, the frame on the KTM 85 SX 2013 impresses with more precise cornering characteristics. Additional aluminium profiles ensure better stability. |
|
General information |
|
Motorcycle name
|
KTM 85 SX 19-16 |
|
Year
|
2013 |
|
Category
|
Cross / motocross |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Displacement
|
84.9 ccm (5.18 cubic inches) |
|
Engine type
|
Single cylinder, two-stroke |
|
Engine details
|
Reed intake. |
|
Bore x stroke
|
47.0 x 49.0 mm (1.9 x 1.9 inches) |
|
Ignition
|
Moric Digital 2M1 |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Multidisc clutch in oil bath/hydraulically activated |
|
Driveline
|
1/2 x 5/16 |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Central tube frame made of chrome molybdenum steel tubing |
|
Rake (fork angle)
|
24.0° |
|
Front suspension
|
WP Suspension USD 35 |
|
Front wheel travel
|
205 mm (8.1 inches) |
|
Rear suspension
|
WP Suspension PDS 4618 BAVP DCC |
|
Rear wheel travel
|
185 mm (7.3 inches) |
|
Front brakes
|
Single disc. Four-piston calipers. |
|
Diameter
|
220 mm (8.7 inches) |
|
Rear brakes
|
Single disc. Two-piston calipers. |
|
Diameter
|
210 mm (8.3 inches) |
|
Physical measures and capacities |
|
Seat height
|
750 mm (29.5 inches) If adjustable, lowest setting. |
|
Ground clearance
|
280 mm (11.0 inches) |
|
Wheelbase
|
1290 mm (50.8 inches) |
|
Fuel capacity
|
5.00 litres (1.32 US gallons) |
|
Other specifications |
|
Color options
|
Orange/black |
|
Starter
|
Kick |
