KTM 85 SX 17-14 20122012 KTM 85 SX 17-14 specifications, pictures, reviews and rating |
| KTM's profilation of this bike |
| The 85 SX masters the toughest MX tracks with unperturbed ease. The grown-up KTM mini-crosser combines fully-fledged MX technology with perfect controllability. |
| General information | |
|---|---|
| Model | KTM 85 SX 17-14 |
| Year of manufacture | 2012 |
| Type | Minibike, cross |
| Rating | 3.4 See the detailed rating of the fun-factor, engine performance, racing track capabilities, etc. Compare with any other bike. |
| Engine and transmission | |
| Engine size | 84.9 ccm (5.18 cubic inches) |
| Type of engine | Single cylinder, two-stroke |
| Bore x stroke | 47.0 x 49.0 mm (1.9 x 1.9 inches) |
| Fuel system | Carburettor. Keihin PWK 28 |
| Ignition | Moric digital 2M1 |
| Lubrication system | Mixture oil lubrication 1:40 |
| Cooling system | Liquid |
| Gearbox | 6-speed |
| Transmission type | Chain (final drive) |
| Clutch | Wet mDouble disk clutch, operated hydraulically |
| Chassis, suspension, brakes and wheels | |
| Frame type | Double grinded central double-cradle-type frame. Subframe: Aluminium. |
| Rake (fork angle) | 24.0° |
| Front suspension | WP USD 43 mm (1.69 in) |
| Front wheel travel | 185 mm (7.3 inches) |
| Rear suspension | WP PDS mono shock |
| Rear wheel travel | 185 mm (7.3 inches) |
| Front tire | 70/100-17 |
| Rear tire | 90/100-14 |
| Front brakes | Single disc |
| Diameter | 220 mm (8.7 inches) |
| Rear brakes | Single disc |
| Diameter | 210 mm (8.3 inches) |
| Wheels | 1.4 x 17in., 1.6 x 14in. Alu |
| Physical measures and capacities | |
| Dry weight | 66.0 kg (145.5 pounds) |
| Seat height | 845 mm (33.3 inches) If adjustable, lowest setting. |
| Wheelbase | 1290 mm (50.8 inches) |
| Fuel capacity | 5.00 litres (1.32 US gallons) |
| Other specifications | |
| Color options | Orange/black/white |
| Starter | Kick |
