| General information |
|---|
| Model: | KTM 690 SMC |
| Year: | 2008 |
| Category: | Super motard |
| Rating: | 3.5 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
| Engine and transmission |
|---|
| Displacement: | 654.0 ccm (39.91 cubic inches) |
| Engine type: | Single cylinder, four-stroke |
| Compression: | 11.8:1 |
| Bore x stroke: | 102.0 x 80.0 mm (4.0 x 3.1 inches) |
| Valves per cylinder: | 4 |
| Fuel control: | Overhead Cams (OHC) |
| Ignition: | Keihin |
| Lubrication system: | Semi-dry-sump lubrication with 2 Eaton pumps |
| Cooling system: | Liquid |
| Gearbox: | 6-speed |
Transmission type,
final drive: | Chain |
| Clutch: | APTC Wet multi-disc clutch, operated hydraulically |
| Exhaust system: | 2-cell stainless seel |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type: | Tubular trellis steel frame (CrMo) |
| Rake (fork angle): | 27.0° |
| Trail: | 112 mm (4.4 inches) |
| Front suspension: | WP USD |
| Front wheel travel: | 275 mm (10.8 inches) |
| Rear suspension: | WP monoshock |
| Rear wheel travel: | 265 mm (10.4 inches) |
| Front tyre: | 120/70-17 |
| Rear tyre: | 160/60-17 |
| Front brakes: | Single disc |
| Diameter: | 300 mm (11.8 inches) |
| Rear brakes: | Single disc |
| Diameter: | 240 mm (9.4 inches) |
| Physical measures and capacities |
|---|
| Dry weight: | 139.5 kg (307.5 pounds) |
| Seat height: | 900 mm (35.4 inches) If adjustable, lowest setting. |
| Ground clearance: | 290 mm (11.4 inches) |
| Wheelbase: | 1480 mm (58.3 inches) |
| Fuel capacity: | 12.00 litres (3.17 gallons) |
| Other specifications |
|---|
| Starter: | Kick |
