General information |
|
Model
|
KTM 690 LC4 Rally Replica |
|
Year of manufacture
|
2008 |
|
Type
|
Enduro / offroad |
|
Rating
|
3.6 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
654.0 ccm (39.91 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Compression
|
11.8:1 |
|
Bore x stroke
|
102.0 x 80.0 mm (4.0 x 3.1 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Carburettor. Keihin THB 46 |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Ignition
|
Keihin |
|
Cooling system
|
Liquid |
|
Gearbox
|
6-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
APTC Wet multi-disc clutch, operated hydraulically |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Tubular trellis steel frame (CrMo) |
|
Rake (fork angle)
|
27.0° |
|
Front suspension
|
WP USD, 48 mm |
|
Front wheel travel
|
250 mm (9.8 inches) |
|
Rear suspension
|
WP monoshock |
|
Rear wheel travel
|
250 mm (9.8 inches) |
|
Front tire
|
90/90-21 |
|
Rear tire
|
140/80-18 |
|
Front brakes
|
Single disc |
|
Rear brakes
|
Single disc |
|
Physical measures and capacities |
|
Seat height
|
910 mm (35.8 inches) If adjustable, lowest setting. |
|
Ground clearance
|
300 mm (11.8 inches) |
|
Wheelbase
|
1498 mm (59.0 inches) |
|
Other specifications |
|
Comments
|
The 690 Rally Replica will be exclusively equipped with race-proven winning technology. |
