KTM 690 Enduro 20082008 KTM 690 Enduro specifications, pictures, reviews and rating |
| General information | |
|---|---|
| Model name | KTM 690 Enduro |
| Year | 2008 |
| Category | Enduro / offroad |
| Rating | 3.8 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
| Engine and transmission | |
| Displacement | 654.0 ccm (39.91 cubic inches) |
| Engine type | Single cylinder, four-stroke |
| Compression | 11.8:1 |
| Bore x stroke | 102.0 x 80.0 mm (4.0 x 3.1 inches) |
| Fuel system | Carburettor. Keihin THB 46 |
| Fuel control | Overhead Cams (OHC) |
| Ignition | Keihin |
| Lubrication system | Semi-dry-sump lubrication with 2 Eaton pumps |
| Cooling system | Liquid |
| Gearbox | 6-speed |
| Transmission type | Chain (final drive) |
| Clutch | APTC Wet multi-disc clutch, operated hydraulically |
| Exhaust system | 2-cell stainless seel |
| Chassis, suspension, brakes and wheels | |
| Frame type | Tubular trellis steel frame (CrMo) |
| Rake (fork angle) | 27.0° |
| Front suspension | WP USD, 48 mm |
| Front wheel travel | 250 mm (9.8 inches) |
| Rear suspension | WP monoshock |
| Rear wheel travel | 250 mm (9.8 inches) |
| Front tire | 90/90-21 |
| Rear tire | 140/80-18 |
| Front brakes | Single disc |
| Rear brakes | Single disc |
| Physical measures and capacities | |
| Dry weight | 138.5 kg (305.3 pounds) |
| Seat height | 910 mm (35.8 inches) If adjustable, lowest setting. |
| Ground clearance | 300 mm (11.8 inches) |
| Wheelbase | 1498 mm (59.0 inches) |
| Fuel capacity | 12.00 litres (3.17 US gallons) |
| Other specifications | |
| Color options | Orange/black |
| Starter | Electric |
| Update specs | Report missing specs or required updates. |
| Further information | |
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Parts finder | Check out our overview of motorcycle webshops at Bikez.info. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 08 KTM 690 Enduro discussion group or the general KTM discussion group. |
| Related bikes | List related bikes for comparison of specs. |
| Compare with another motorcycle | |
Discussions for every bike
Bikez has discussion forums for every bike. View comments, questions and answers at the 2008 KTM 690 Enduro discussion group. You can sign up for e-mail notifications when other riders answer you. If you have extensive experience with the MC, please send us a review. If you consider buying this bike, you should view the list of related motorbikes Look at photos. Compare technical specs. And check out the rating of the bike's engine performance, reliability, repair costs, etc. You can compare the rating with other bikes.| Rating sample for this KTM bike | |
Reliability for the 2008 KTM 690 Enduro:  (76.8 out of 100)Click here for complete rating. |
|
