| KTM's profilation of this bike |
| As a worthy successor to the legendary Super Competition, the 625 SXC shows its sporty talents on all terrains. The legendary LC 4 motor in its current development stage convinces with agile high revving and enormous torque. |
|
General information |
|
Model name
|
KTM 625 SXC |
|
Model year
|
2005 |
|
Category
|
Cross / motocross |
|
Rating
|
3.5 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
625.0 ccm (38.14 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Compression
|
11.7:1 |
|
Bore x stroke
|
101.0 x 78.0 mm (4.0 x 3.1 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Carburettor. Keihin MX FCR 41 |
|
Fuel control
|
Overhead Cams (OHC) |
|
Ignition
|
Kokusan DC-CDI |
|
Lubrication system
|
Pressure lubrication with 2 Eaton pumps |
|
Cooling system
|
Liquid |
|
Gearbox
|
5-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Wet multi-disc clutch, operated hydraulically |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Chromium-molybdenum, powder-coated |
|
Rake (fork angle)
|
27.5° |
|
Trail
|
124 mm (4.9 inches) |
|
Front suspension
|
WP-USD 43 mm (1.89ยด) |
|
Rear suspension
|
WP Monoshock |
|
Rear wheel travel
|
335 mm (13.2 inches) |
|
Front tire
|
90/90-21 |
|
Front brakes
|
Single disc |
|
Diameter
|
216 mm (8.5 inches) |
|
Rear brakes
|
Single disc |
|
Diameter
|
260 mm (10.2 inches) |
|
Physical measures and capacities |
|
Dry weight
|
139.0 kg (306.4 pounds) |
|
Seat height
|
980 mm (38.6 inches) If adjustable, lowest setting. |
|
Overall height
|
625 mm (24.6 inches) |
|
Overall width
|
625 mm (24.6 inches) |
|
Ground clearance
|
330 mm (13.0 inches) |
|
Wheelbase
|
1510 mm (59.4 inches) |
|
Fuel capacity
|
9.20 litres (2.43 US gallons) |
|
Other specifications |
|
Starter
|
Electric & kick |
