KTM 625 SXC 20052005 KTM 625 SXC specifications, pictures, reviews and rating |
| KTM's profilation of this bike |
| As a worthy successor to the legendary Super Competition, the 625 SXC shows its sporty talents on all terrains. The legendary LC 4 motor in its current development stage convinces with agile high revving and enormous torque. |
| General information | |
|---|---|
| Model name | KTM 625 SXC |
| Model year | 2005 |
| Category | Cross / motocross |
| Rating | 3.5 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
| Engine and transmission | |
| Displacement | 625.0 ccm (38.14 cubic inches) |
| Engine type | Single cylinder, four-stroke |
| Compression | 11.7:1 |
| Bore x stroke | 101.0 x 78.0 mm (4.0 x 3.1 inches) |
| Valves per cylinder | 4 |
| Fuel system | Carburettor. Keihin MX FCR 41 |
| Fuel control | Overhead Cams (OHC) |
| Ignition | Kokusan DC-CDI |
| Lubrication system | Pressure lubrication with 2 Eaton pumps |
| Cooling system | Liquid |
| Gearbox | 5-speed |
| Transmission type | Chain (final drive) |
| Clutch | Wet multi-disc clutch, operated hydraulically |
| Chassis, suspension, brakes and wheels | |
| Frame type | Chromium-molybdenum, powder-coated |
| Rake (fork angle) | 27.5° |
| Trail | 124 mm (4.9 inches) |
| Front suspension | WP-USD 43 mm (1.89´) |
| Rear suspension | WP Monoshock |
| Rear wheel travel | 335 mm (13.2 inches) |
| Front tire | 90/90-21 |
| Front brakes | Single disc |
| Diameter | 216 mm (8.5 inches) |
| Rear brakes | Single disc |
| Diameter | 260 mm (10.2 inches) |
| Physical measures and capacities | |
| Dry weight | 139.0 kg (306.4 pounds) |
| Seat height | 980 mm (38.6 inches) If adjustable, lowest setting. |
| Overall height | 625 mm (24.6 inches) |
| Overall width | 625 mm (24.6 inches) |
| Ground clearance | 330 mm (13.0 inches) |
| Wheelbase | 1510 mm (59.4 inches) |
| Fuel capacity | 9.20 litres (2.43 US gallons) |
| Other specifications | |
| Starter | Electric & kick |
