General information |
|
Model
|
KTM 620 EGS |
|
Model year
|
1998 |
|
Category
|
Enduro / offroad |
|
Rating
|
3.6 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Displacement
|
609.0 ccm (37.16 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Power output
|
50.0 HP (36.5 kW)) @ 7250 RPM |
|
Torque
|
60.0 Nm (6.1 kgf-m or 44.3 ft.lbs) @ 5500 RPM |
|
Top speed
|
155.0 km/h (96.3 mph) |
|
Compression
|
10.4:1 |
|
Bore x stroke
|
101.0 x 76.0 mm (4.0 x 3.0 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Carburettor. Dell´Orto PHM 40 SD |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Ignition
|
KDC-CDI |
|
Cooling system
|
Liquid |
|
Gearbox
|
5-speed |
|
Transmission type
|
Chain (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
WP Telescopic forks, compression and rebound adjustable |
|
Rear suspension
|
Single chock, preload, compression and rebound adjustable |
|
Front tire
|
90/90-21 |
|
Rear tire
|
130/80-18 |
|
Front brakes
|
Single disc. Four-piston calipers. |
|
Diameter
|
320 mm (12.6 inches) |
|
Rear brakes
|
Single disc. Single-piston caliper. |
|
Diameter
|
220 mm (8.7 inches) |
|
Physical measures and capacities |
|
Dry weight
|
131.0 kg (288.8 pounds) |
|
Weight incl. oil, gas, etc
|
139.0 kg (306.4 pounds) |
|
Power/weight ratio
|
0.3817 HP/kg |
|
Seat height
|
940 mm (37.0 inches) If adjustable, lowest setting. |
|
Fuel capacity
|
11.00 litres (2.91 US gallons) |
|
Oil capacity
|
2.10 litres (2.22 US quarts) |
|
Other specifications |
|
Starter
|
Electric & kick |
| Update specs | Report missing specs or required updates. |
|
Maintenance and service specs * |
|
Engine oil
|
15W-50 |
|
Brake fluid
|
DOT 5.1 |
|
Coolant
|
1.00 litres (0.26 US gallons) |
|
Spark plugs
|
NGK D8EA, NGK DR8EIX |
|
Chain links
|
110 |
|
Sprockets
|
16/44 (front/rear) |
|
Tire pressure front
|
36 PSI (2.5 Bar or 250 kPa) |
|
Tire pressure rear
|
36 PSI (2.5 Bar or 250 kPa) |
|
Fork tube size
|
40 mm (1.6 inches) |
| *) Always verify maintenance and service data with the bike owner's manual. |
|
