| KTM's profilation of this bike |
| The entry level bike for kids from 3 years and up. Controllable power is nice and easily delivered to the rear knobbly tyre thanks to the centrifugal clutch. With a weat height of 530 mm it is also safe for little ones to ride.
|
|
General moped information |
|
Motorcycle name
|
KTM 50 Mini Adventure |
|
Year model
|
2005 |
|
Type
|
Minibike, cross |
|
Rating
|
3.6 See the detailed rating of the fun-factor, engine performance, racing track capabilities, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
49.0 ccm (2.99 cubic inches) |
|
Type of engine
|
Single cylinder, two-stroke |
|
Bore x stroke
|
39.5 x 40.0 mm (1.6 x 1.6 inches) |
|
Fuel system
|
Carburettor. Dell´Orto PHVA 12 XS |
|
Ignition
|
Seletra analogue |
|
Cooling system
|
Air |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
Centrifugal clutch (adjustable) |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Central double-cradle-type frame |
|
Rake (fork angle)
|
24.0° |
|
Trail
|
74 mm (2.9 inches) |
|
Front suspension
|
Marzocchi Ø |
|
Front wheel travel
|
32 mm (1.3 inches) |
|
Rear suspension
|
Paioli monoshock |
|
Front brakes
|
Expanding brake (drum brake) |
|
Diameter
|
216 mm (8.5 inches) |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Diameter
|
216 mm (8.5 inches) |
|
Physical measures and capacities |
|
Dry weight
|
37.8 kg (83.3 pounds) |
|
Seat height
|
530 mm (20.9 inches) If adjustable, lowest setting. |
|
Ground clearance
|
190 mm (7.5 inches) |
|
Wheelbase
|
905 mm (35.6 inches) |
|
Fuel capacity
|
2.00 litres (0.53 US gallons) |
|
Other specifications |
| Update specs | Report missing specs or required updates. |
|
Further information |
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Parts finder |
Check out our overview of motorcycle webshops at Bikez.info. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 05 KTM 50 Mini Adventure discussion group or the general KTM discussion group. |
| Related bikes | List related bikes for comparison of specs. |
|
|
|
Rating sample for this KTM moped
|
Fun-factor for the 2005 KTM 50 Mini Adventure:
 (78.5 out of 100)
Click here for complete rating. You can also compare bikes.
|
|
