KTM 505 SX 20132013 KTM 505 SX specifications, pictures, reviews and rating |
| KTM's profilation of this bike |
| The Motocross-Quad 505 SX is a thoroughbred racing machine and just as uncompromisingly designed for victory as the MX motorcycles from KTM. Every single detail takes account of this requirement, from the elaborate ergonomics to the multi-adjustable chassis. In conjunction with low vehicle weight and the low centre of gravity, the powerful DOHC racing engine ensures exceptional performance on every track. |
| General information | |
|---|---|
| Model | KTM 505 SX |
| Year model | 2013 |
| Type | ATV |
| Rating |
Do you know this bike? Click here to rate it. We miss 2 votes to show the rating. |
| Engine and transmission | |
| Engine size | 477.5 ccm (29.14 cubic inches) |
| Type of engine | Single cylinder, four-stroke |
| Bore x stroke | 100.0 x 60.8 mm (3.9 x 2.4 inches) |
| Ignition | Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment, type Kokusan |
| Lubrication system | Forced oil lubrication with 2 Eaton pumps |
| Cooling system | Liquid |
| Clutch | Wet multi-disc clutch / hydraulically operated |
| Driveline | 5/8 x 1/4 |
| Chassis, suspension, brakes and wheels | |
| Frame type | Double-cradle frame made from chrome-molybdenum steel tubing, powder-coated |
| Front suspension | Independent wheels suspension with double wishbone |
| Front wheel travel | 275 mm (10.8 inches) |
| Rear suspension | Rigid axle |
| Rear wheel travel | 272 mm (10.7 inches) |
| Front brakes | Single disc |
| Diameter | 180 mm (7.1 inches) |
| Rear brakes | Single disc |
| Diameter | 200 mm (7.9 inches) |
| Physical measures and capacities | |
| Seat height | 795 mm (31.3 inches) If adjustable, lowest setting. |
| Ground clearance | 265 mm (10.4 inches) |
| Wheelbase | 1280 mm (50.4 inches) |
| Other specifications | |
| Color options | Orange |
| Starter | Electric |
