KTM 450 SX-F 20092009 KTM 450 SX-F specifications, pictures, reviews and rating |
| KTM's profilation of this bike |
| Not a bike but a racing machine which is the main contender on all tracks. As well as the revolutionary engine, this bike also has an extremely light chassis and trend-setting running gear. For 2009, the 450 SX-F (like the 250 SX-F) has been trimmed at the factory specifically for MX1 series wins: with huge numbers of great PowerParts! |
| General information | |
|---|---|
| Model | KTM 450 SX-F |
| Year model | 2009 |
| Type | Enduro / offroad |
| Rating | 3.8 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
| Engine and transmission | |
| Engine size | 449.3 ccm (27.42 cubic inches) |
| Type of engine | Single cylinder, four-stroke |
| Compression | 12.5:1 |
| Bore x stroke | 97.0 x 60.8 mm (3.8 x 2.4 inches) |
| Valves per cylinder | 4 |
| Fuel system | Carburettor. Keihin MX FCR 41 |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Ignition | Kokusan digital DC-CDI |
| Lubrication system | Pressure lubrication |
| Cooling system | Liquid |
| Gearbox | 4-speed |
| Transmission type | Chain (final drive) |
| Clutch | Wet multi-disc clutch, operated hydraulically |
| Exhaust system | Aluminium |
| Chassis, suspension, brakes and wheels | |
| Frame type | Central double-cradle-type 25 CrMo4. Aluminium subframe. |
| Rake (fork angle) | 26.5° |
| Front suspension | WP USD |
| Front wheel travel | 300 mm (11.8 inches) |
| Rear suspension | WP PDS shock absorber |
| Rear wheel travel | 335 mm (13.2 inches) |
| Front tire | 80/100-21 |
| Rear tire | 110/90-19 |
| Front brakes | Single disc |
| Diameter | 260 mm (10.2 inches) |
| Rear brakes | Single disc |
| Diameter | 220 mm (8.7 inches) |
| Physical measures and capacities | |
| Dry weight | 104.6 kg (230.6 pounds) |
| Seat height | 985 mm (38.8 inches) If adjustable, lowest setting. |
| Ground clearance | 380 mm (15.0 inches) |
| Wheelbase | 1475 mm (58.1 inches) |
| Fuel capacity | 8.00 litres (2.11 US gallons) |
| Other specifications | |
| Color options | Orange |
| Starter | Electric |
| Update specs | Report missing specs or required updates. |
| Further information | |
| Insurance costs | Compare US insurance quotes from the nation's top providers. |
| Parts finder | Check out our overview of motorcycle webshops at Bikez.info. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 09 KTM 450 SX-F discussion group or the general KTM discussion group. |
| Related bikes | List related bikes for comparison of specs. |
| Compare with another motorcycle | |
Buying a bike starts at Bikez
Get a list of related motorbikes before you buy this KTM. Inspect technical data. Look at photos. Read the riders' comments at the bike's discussion group. And check out the bike's reliability, repair costs, etc. Show any 2009 KTM 450 SX-F for sale on our Bikez.biz Motorcycle Classifieds. You can also sign up for e-mail notification when such bikes are advertised in the future. And advertise your old MC for sale. Our efficient ads are free. You are also welcome to read and submit motorcycle reviews.| Rating sample for this KTM bike | |
Engine performance for the 2009 KTM 450 SX-F:  (84.0 out of 100)Click here for complete rating. |
|
