| KTM's profilation of this bike |
| The new 450 SMR is pretty much the hottest standard Supermoto model currently on the market. This thoroughbred racing bike was developed for the KTM factory team according to the motto “Ready to Race” and was successfully tested at the 2007 World Championships. And this same weapon for the S1 class is now waiting on the showroom floor for you. |
|
General information |
|
Motorcycle name
|
KTM 450 SMR |
|
Year of manufacture
|
2009 |
|
Type
|
Super motard |
|
Rating
|
3.3 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
|
Engine and transmission |
|
Engine size
|
449.3 ccm (27.42 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Compression
|
12.5:1 |
|
Bore x stroke
|
97.0 x 60.8 mm (3.8 x 2.4 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Carburettor. Keihin MX FCR 41 |
|
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
|
Ignition
|
Kokusan |
|
Lubrication system
|
Pressure lubrication |
|
Cooling system
|
Liquid |
|
Gearbox
|
5-speed |
|
Transmission type
|
Chain (final drive) |
|
Clutch
|
APTC Antihopping, operated hydraulically |
|
Chassis, suspension, brakes and wheels |
|
Frame type
|
Chromium-Molybdenum central double-cradle-type frame, powder coated. Aluminium subframe. |
|
Rake (fork angle)
|
26.5° |
|
Trail
|
119 mm (4.7 inches) |
|
Front suspension
|
WP USD |
|
Front wheel travel
|
280 mm (11.0 inches) |
|
Rear suspension
|
WP PDS mono shock |
|
Rear wheel travel
|
310 mm (12.2 inches) |
|
Front tire
|
125/80-R20 |
|
Rear tire
|
170/55-R17 |
|
Front brakes
|
Single disc. Magura four piston, radially bolted caliper |
|
Diameter
|
310 mm (12.2 inches) |
|
Rear brakes
|
Single disc. Brembo single-piston, floating caliper |
|
Diameter
|
220 mm (8.7 inches) |
|
Physical measures and capacities |
|
Dry weight
|
111.5 kg (245.8 pounds) |
|
Seat height
|
920 mm (36.2 inches) If adjustable, lowest setting. |
|
Ground clearance
|
300 mm (11.8 inches) |
|
Wheelbase
|
1475 mm (58.1 inches) |
|
Fuel capacity
|
8.20 litres (2.17 US gallons) |
|
Other specifications |
|
Color options
|
Orange |
|
Starter
|
Electric |
