KTM 450 SMR 20062006 KTM 450 SMR specifications, pictures, reviews and rating |
| KTM's profilation of this bike |
| The ultra-light racing machine for the S2 Supermoto class. Special Supermoto chassis, High Performance racing brkae up front, with a radial caliper and radial pump and plenty of power that´s transferred to the 5 inches rear wheel at the highest speeds. |
| General information | |
|---|---|
| Model | KTM 450 SMR |
| Year | 2006 |
| Category | Super motard |
| Rating | 3.5 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
| Engine and transmission | |
| Displacement | 449.4 ccm (27.42 cubic inches) |
| Engine type | Single cylinder, four-stroke |
| Torque | 42.5 Nm (4.3 kgf-m or 31.3 ft.lbs) @ 3250 RPM |
| Compression | 12.0:1 |
| Bore x stroke | 95.0 x 63.4 mm (3.7 x 2.5 inches) |
| Fuel system | Carburettor. Mikuni BST 40 |
| Fuel control | Overhead Cams (OHC) |
| Ignition | Kokusan digital 4K-3A |
| Lubrication system | Pressure lubrication with 2 oil pumps |
| Cooling system | Liquid |
| Gearbox | 6-speed |
| Transmission type | Chain (final drive) |
| Clutch | Multi-disc wet clutch, hydraulically operated |
| Exhaust system | Aluminum |
| Chassis, suspension, brakes and wheels | |
| Frame type | Double ground, chrome-moly-steel frame, powder-coated |
| Rake (fork angle) | 26.5° |
| Trail | 90 mm (3.5 inches) |
| Front suspension | WP-USD 48 mm (1.89 inches) |
| Front wheel travel | 300 mm (11.8 inches) |
| Rear suspension | WP-PDS shock absorber |
| Rear wheel travel | 335 mm (13.2 inches) |
| Front tire | 120/75-17 |
| Rear tire | 165/55-17 |
| Front brakes | Single disc |
| Diameter | 310 mm (12.2 inches) |
| Rear brakes | Single disc |
| Diameter | 220 mm (8.7 inches) |
| Physical measures and capacities | |
| Dry weight | 108.5 kg (239.2 pounds) |
| Seat height | 855 mm (33.7 inches) If adjustable, lowest setting. |
| Overall width | 450 mm (17.7 inches) |
| Ground clearance | 310 mm (12.2 inches) |
| Wheelbase | 1481 mm (58.3 inches) |
| Fuel capacity | 7.00 litres (1.85 US gallons) |
| Other specifications | |
| Starter | Kick |
