KTM's profilation of this bike |
Controllable power output together with racing oriented peak power characterise the 450 EXC as the ideal 4-stroke competition enduro in it´s class.
|
General information |
Model
|
KTM 450 EXC Racing |
Year
|
2004 |
Category
|
Enduro / offroad |
Rating
|
4.1 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
Engine and transmission |
Displacement
|
447.9 ccm (27.33 cubic inches) |
Engine type
|
Single cylinder, four-stroke |
Compression
|
11.0:1 |
Bore x stroke
|
89.0 x 72.0 mm (3.5 x 2.8 inches) |
Valves per cylinder
|
4 |
Fuel system
|
Carburettor. Keihin MC FCR 39 |
Fuel control
|
Overhead Cams (OHC) |
Ignition
|
Kokusan digital |
Lubrication system
|
Pressure lubrication with 3 Eaton pumps |
Cooling system
|
Liquid |
Gearbox
|
6-speed |
Transmission type
|
Chain (final drive) |
Clutch
|
Wet multi-disc clutch, operated hydraulically |
Chassis, suspension, brakes and wheels |
Frame type
|
Chrome molybdenum |
Trail
|
64 mm (2.5 inches) |
Front suspension
|
WP-USD 48 MA |
Front wheel travel
|
300 mm (11.8 inches) |
Rear suspension
|
WP-PDS-shock absorber |
Rear wheel travel
|
335 mm (13.2 inches) |
Front tire
|
90/90-21 |
Rear tire
|
140/80-18 |
Front brakes
|
Single disc |
Diameter
|
260 mm (10.2 inches) |
Rear brakes
|
Single disc |
Diameter
|
216 mm (8.5 inches) |
Physical measures and capacities |
Dry weight
|
117.2 kg (258.4 pounds) |
Seat height
|
925 mm (36.4 inches) If adjustable, lowest setting. |
Alternate seat height
|
675 mm (26.6 inches) If adjustable, highest setting. |
Overall width
|
450 mm (17.7 inches) |
Ground clearance
|
385 mm (15.2 inches) |
Wheelbase
|
1481 mm (58.3 inches) |
Fuel capacity
|
8.50 litres (2.25 US gallons) |
Oil capacity
|
1.30 litres (1.37 US quarts) |
Other specifications |
Color options
|
Orange |
Update specs | Report missing specs or required updates. |
Maintenance and service specs * |
Engine oil
|
SAE 15W-50 Synthetic |
Brake fluid
|
DOT 4 |
Coolant
|
1.00 litres (0.26 US gallons) |
Spark plugs
|
NGK DCPR8E, NGK DCPR8EIX |
Chain size
|
520 |
Chain links
|
118 |
Sprockets
|
15/45 (front/rear) |
Fork tube size
|
48 mm (1.9 inches) |
*) Always verify maintenance and service data with the bike owner's manual. |
